BUR YAZ382NT38FX CU HYLUG 700KCMIL
Product image thumbnail 0
Product image thumbnail 1
Product image thumbnail 2
$139.41/ea
Usually ships within 11 to 17 Days
ea
Adding...
Already a Customer? Log in to view your pricing
Manufacturer Burndy
Mfg Catalog # YAZ382NT38FX
North Coast Part # 600869

Features

  • UL Listed 90 DEG C, 600 V - 35 KV, 45 DEG And 90 DEG Angles Are Available, With Inspection Window, Temperature Rating: 90 DEG C, Die Index: L99, Finish: Electro-Tin Plated, Wire Strip Length: 2-7/8 IN, Tongue Angle: Straight, Color Code: Pink, Tools, Die Set Catalog Number, And (number Of Crimps): Hydraulic: Y35, Y39, Y750, PAT750 Tool, U38XRT Die, (4), Y46 Tool, U38XRT Die With PUADP-1 Adapter, (4), Conductor Type: Flexible, Dieless Tools (number Of Crimps): Y644HS Tool, (1), Y81KFT, Y81KFTMBH, PAT81KFT-18V Tool, (2)

Specifications

  • Conductor - Copper DLO Size: 535.3 (1325/#24) DLO
  • Conductor - Copper DLO Size Range: 535 kcmil
  • Conductor - Copper Flex G Size: 500 kcmil
  • Conductor - Copper Flex G Size Range: 550 kcmil
  • Conductor - Copper Flex H Size: 500 kcmil
  • Conductor - Copper Flex H Size Range: 500 / 550 kcmil
  • Conductor - Copper Flex I Size: 500 kcmil
  • Conductor - Copper Flex I Size Range: 500 / 550 kcmil
  • Conductor - Copper Flex K Size: 500 kcmil
  • Conductor - Copper Flex K Size Range: 500 kcmil
  • Conductor - Copper Flex M Size: 500 kcmil
  • Conductor - Copper Str Size Range: 500 / 550 kcmil
  • Country of Origin: US
  • Dimension - B Length fraction: 2-13/16 in
  • Dimension - B Length inch: 2.81 in
  • Dimension - Bolt Hole Size inch: 0.39 in
  • Dimension - Bolt Size fraction: 3/8
  • Dimension - Diameter Min Size inch: 2.03 in
  • Dimension - L Length Overall mm: 145 mm
  • Dimension - Length Overall inch: 5.72 in
  • Dimension - Length Side B inch: 5.72 in
  • Dimension - N inch: 0.50 in
  • Dimension - Outside Diameter inch: 1.25 in
  • Dimension - Pad Width inch: 1.62 in
  • Dimension - Strip Length inch: 2-7/8
  • Dimension - Stud Size inch: 3/8 in
  • Dimension - Z inch: 0.52 in
  • Each - Height: 0.000 in
  • Each - Length: 0.000 in
  • Each - Width: 0.000 in
  • Feature - Barrel Style: Skived
  • Feature - Barrel Type: Long
  • Physical Attribute - Number of Holes: 2
  • Physical Attribute - Tongue Angle: Straight
  • Plated: Y
  • Plating Type: Tin - Electro Plated
  • Product Type: Compression
  • Rating - KVA: 35 kV
  • Show Add To ProjectList: Yes
  • Standards - RoHS Compliance Status: CM
  • Trade Name: HYLUG™
  • Sub Brand: HYLUG

Certifications

  • CSA Approved: Yes
  • cULus: No
  • ETL: No
  • UL Recognized: No
  • EU RoHS Indicator: Yes

Overview

UPC 78181016611
Item Long Description Copper Compression Lug, 2 Hole w/ Inspection Window, 535.3 Flex, 3/8" Stud, 1" Stud Hole Spacing, Long Barrel, Tin Plated.
GTiN 00781810166116
Type YAZ-2-NTFX, Long Barrel Narrow Tongue
Material Copper
Stud Size 0.375 in
Number of Holes 2 Hole
Applications For Flex Conductors
Cable Size 535.3 KCMIL, 500 KCMIL Flex, 1325/24, 300 SQ-MM For Class 5 Conductor
Family Brand Name Burndy
Sub Brand HYLUG
Length 5.72 in
Connection Type Terminal
Plating Type Tin - Electro Plated
Plated? Yes
CSA Yes
Max Voltage 35000 V
Color Coding Pink
