BUR YGIBS284622N .462 STD FLNG, 2-4
Product image thumbnail 0
Product image thumbnail 1
Product image thumbnail 2
$163.27/ea
Usually ships within 11 to 17 Days
ea
Adding...
Already a Customer? Log in to view your pricing
Manufacturer Burndy
Mfg Catalog # YGIBS284622N
North Coast Part # 159954

Specifications

  • Conductor - Copper Str Size: 2 AWG;1 AWG;1/0 ;2/0 AWG;3/0 AWG;4/0 AWG
  • Conductor - Copper Str Size Range: 2 AWG-4/0 AWG
  • Country of Origin: US
  • Dimension - B Length fraction: 3 in
  • Dimension - B Length inch: 3.00 in
  • Dimension - I Beam Thickness inch: 0.400" - 0.462"
  • Dimension - I Beam Thickness Range inch: 0.376;0.400;0.425;0.437
  • Dimension - L Length Overall mm: 76 mm
  • Dimension - Length Overall inch: 3.00 in
  • Each - Height: 0.000 in
  • Each - Length: 0.000 in
  • Each - Width: 0.000 in
  • I Beam Style: Standard Beam (Flange Angled)
  • Industry Standard(s): UL467
  • Plated: N
  • Plating Type: Unplated
  • Product Type: Compression
  • Show Add To ProjectList: Yes
  • Standards - Industry Standards Met: UL467
  • Standards - RoHS Compliance Status: CM
  • Trade Name: GROUNDLINK™

Certifications

  • CSA Approved: Yes
  • cULus: No
  • ETL: No
  • UL Listed Direct Burial: Yes
  • UL Recognized: No

Overview

UPC 78181003930
GTiN 00781810039304
Family Brand Name Hubbell
Item Long Description Copper Compression Connector, Cable to Steel, 2 AWG - 4/0 AWG, Angled Flange, 0.400" - 0.462" Thickness, 2 holes, 1/2" Stud.
Length 3.00 in
Material Copper
Conductor Size 1 AWG
Connection Type Tap
Plating Type Unplated
Conductor Type CU C Str-Size
Plated? No
CSA Yes
