BUSS 170M5811D FUSE 550A 690V aR DI
$411.10/ea
Usually ships within 6 to 8 Days
ea
Adding...
Already a Customer? Log in to view your pricing
Manufacturer Cooper / Bussman
Mfg Catalog # 170M5811D
North Coast Part # 827046

Specifications

  • Height: 71 MM
  • Length: 150 MM
  • Width: 55 MM
  • Weight: 674 G
  • Type: Fuse
  • Application: industrial
  • Voltage Rating: 700V (UL), 690V (IEC)
  • Voltage Rating Numeric: 690 V
  • Amperage Rating: 550A
  • Amperage Rating Numeric: 550 A
  • Interrupt Rating: 200 kAIC
  • Class: Class aR
  • Connection: Din 43-620 blade end X Din 43-620 blade end
  • Construction Size: Other
  • Packaging Type: Standard
  • Clearing (I2T): Clearing at 660V: 215000
  • Fuse Shape: square body with knife blade contacts
  • Fuse Indicator: Combination fuse status indicator
  • Insulated Metal Gripping Lugs (IMGL): No
  • Pre Arc (I2T): 29000
  • Utilization category: aR (accompanied semiconductor protection)
  • Voltage Type: AC
  • Watt Losses: 36W

Overview

UPC 05171233451
GTiN 00051712334518
Length 150 mm
Width 55 mm
Size 150 mm Length X 55 mm Width X 71 mm Height
Voltage 700 Volt
Type Fuse
Applications DC Common Bus, DC Drives, Power Converters/Rectifiers, Reduced Voltage Starters
Height 71 mm
Weight 674 g
Standard CE,IEC 60269,UL
Connection Type Blade
Fuse Type DIN 43-620
Family Brand Name Bussmann Series
Class Class AR
TC Connection DIN 43-620 Blade End X DIN 43-620 Blade End
Amperage 550 Amp
End Type Blade
Interrupt Rating 200 kA
