BUSS ECNR175 UL CLASS RK-5 TIME DEL
Product image thumbnail 0
Product image thumbnail 1
Product image thumbnail 2
$134.05/ea
Usually ships within 6 to 8 Days
ea
Adding...
Already a Customer? Log in to view your pricing
Manufacturer Cooper / Bussman
Mfg Catalog # ECNR175
North Coast Part # 1687019

Specifications

  • Height: 7.13 IN
  • Length: 1.56 IN
  • Width: 1.56 IN
  • Weight: .85 LB
  • Type: Time delay, Current-limiting
  • Special Features: Superior overload and cycling capabilities
  • Voltage Rating: 250 Vac, 125 Vdc
  • Amperage Rating: 175A
  • Interrupt Rating: 200 kAIC
  • Class: Class RK5
  • Connection: Blade end X blade end
  • Packaging Type: Standard
  • Diameter: 1.56 IN
  • Fuse Indicator: Non Indicating
  • Response Time: 10s at 500%
  • Number Of Elements: Dual

Categories

Overview

UPC 78263450747
Item Long Description Eaton Edison ECNR fuse, Superior overload and cycling capabilities, 250 Vac, 125 Vdc, 175A, 200 kAIC, Non Indicating, Time delay, Current-limiting, Blade end X blade end, Class RK5
GTiN 00782634507475
Length 1.56 in
Width 1.56 in
Size 1.56 In Diameter X 7.13 In Length
Voltage 125 Volt
Type Current Limiting,Time-Delay
Diameter 1.56 in
Applications AC Power Distribution System Mains, Feeders and Branch Circuits, Protection of Motor and Motor Branch Circuits, Transformers and Other Inductive Loa
Height 7.13 in
Weight .85 lb
Standard CSA C22.2,UL
Connection Type Blade
Family Brand Name Bussmann Series
Class Class RK5
TC Connection Blade End X Blade End
Amperage 175 Amp
Response Time 10 seconds at 500%
End Type Blade
Interrupt Rating 200 kA
Element Dual
Sub Brand Edison
Blade Dimensions 7.1300 IN X 1.5600 IN X 1.5600 IN
