Bussmann Series FWH-350A High Speed Fuse
Product image thumbnail 0
Product image thumbnail 1
Product image thumbnail 2
Product image thumbnail 3
Already a Customer? Log in to view your pricing
Manufacturer Cooper / Bussman
Mfg Catalog # FWH-350A
North Coast Part # 214227


  • Height: 1.61 IN
  • Length: 1.69 IN
  • Width: 4.52 IN
  • Weight: .52 LB
  • Type: FWH, North American style
  • Application: DC common bus, DC drives, power converters/rectifiers, reduced voltage starters
  • Voltage Rating: 1000 Vac, 800 Vdc
  • Amperage Rating: 350A RMS
  • Interrupt Rating: 200 kAIC at 1000 Vac, 50 kAIC at 500 Vdc
  • Connection: Blade end X blade end
  • Mounting: Stud
  • Packaging Type: Standard
  • Clearing (I2T): Clearing at 500V: 72900
  • Fuse Indicator: Non Indicating
  • Pre Arc (I2T): 14500
  • Watt Losses: 58W


UPC 05171215017
Item Long Description Eaton Bussmann series FWH high speed fuse, 1000 Vac, 800 Vdc, 350A RMS, 200 kAIC at 1000 Vac, 50 kAIC at 500 Vdc, Non Indicating, High speed fuse, Blade end X blade end, Stud
GTiN 00051712150170
Length 1.69 in
Width 4.52 in
Size 1.50 In Diameter X 4.34 In Length
Voltage 1000 Volt
Type FWH, North American Style
Applications Ind Facilities & Factories - Facility: Safety and Security Systems
Mounting Type Stud
Height 1.61 in
Weight .52 lb
Connection Type Blade
Family Brand Name Bussmann Series
TC Connection Blade end x blade end
Amperage 350 Amp
End Type Blade
Interrupt Rating 200 kA
Blade Dimensions 1.6900 IN X 4.5200 IN X 1.6100 IN
Sub Brand Bussmann Series
