Bussmann Series FWP-40A14F 14.3 x 50.8 mm 40 Amp AC Ferrule
Product image thumbnail 0
Product image thumbnail 1
Product image thumbnail 2
Product image thumbnail 3
$98.72/ea
Usually ships within 6 to 8 Days
ea
Adding...
Already a Customer? Log in to view your pricing
Manufacturer Cooper / Bussman
Mfg Catalog # FWP-40A14F
North Coast Part # 11096

Specifications

  • Height: 14 MM
  • Length: 51 MM
  • Width: 14 MM
  • Weight: 21.2 G
  • Type: Fuse
  • Application: protection of DC common bus, DC drives, power converters/rectifiers and reduced voltage starters
  • Voltage Rating: 700 Vac (IEC), 800 Vdc (UL), 690 Vac (IEC)
  • Voltage Rating Numeric: 700 V
  • Amperage Rating: 40A
  • Amperage Rating Numeric: 40 A
  • Interrupt Rating: 200 kAIC at 300 Vdc, 50 kAIC at 300 Vdc
  • Class: Class aR
  • Color: White
  • Connection: Ferrule end X ferrule end
  • Construction Size: 14 x 51 mm
  • Material Type: Ceramic
  • Packaging Type: Standard
  • Diameter: 14 MM
  • Quantity: 10
  • Used With: Finger safe holders/blocks and striker
  • Breaking Capacity: 200 A
  • Clearing (I2T): 750
  • Frequency Rating Maximum: 62 HZ
  • Frequency Rating Minimum: 45 HZ
  • Fuse Shape: cylindrical
  • Fuse Indicator: Non Indicating
  • Minimum Melting: 84 I2t (A2 Sec)
  • Pre Arc (I2T): 84
  • Release Characteristic: Other
  • Utilization category: aR (accompanied semiconductor protection)
  • Voltage Type: AC/DC
  • Watt Losses: 8
  • With Striker: No

Categories

Overview

GTiN 00051712796507
Length 51 mm
Width 14 mm
Size 0.563 In Diameter X 2.000 In Length
Color White
Voltage 690 Volt
Type Fuse
Diameter 14 mm
Applications Ind Facilities & Factories - Facility: Safety and Security SystemsInd Facilities & Factories - Facility: Critical PowerElec Assemblies, Panels & EOEM - Electrical Assemblies, Panels and EOEMsElec Assemblies, Panels & EOEM - Electrical Assemblies and EOEMs - Other
Height 14 mm
Weight 21.2 g
Standard CE,UL
Connection Type Ferrule
Family Brand Name Bussmann Series
Class Class AR
TC Connection Ferrule end x ferrule end
Amperage 40 Amp
End Type Ferrule
Interrupt Rating 200 kA
Product UPC 05171279650
Material Ceramic
Blade Dimensions 2.0079 IN X 0.5512 IN X 0.5512 IN
Sub Brand Bussmann Series
