Bussmann Series FWP-63A22F 22 x 58 mm Ferrule 63 Amp AC
Product image thumbnail 0
Product image thumbnail 1
Product image thumbnail 2
Product image thumbnail 3
$120.88/ea
Usually ships within 6 to 8 Days
ea
Adding...
Already a Customer? Log in to view your pricing
Manufacturer Cooper / Bussman
Mfg Catalog # FWP-63A22F
North Coast Part # 10797

Specifications

  • Height: 22 MM
  • Length: 58 MM
  • Width: 22 MM
  • Weight: 62.6 G
  • Type: Fuse
  • Application: protection of DC common bus, DC drives, power converters/rectifiers and reduced voltage starters
  • Voltage Rating: 700 Vac, 700 Vdc (UL)
  • Voltage Rating Numeric: 700 V
  • Amperage Rating: 63A
  • Amperage Rating Numeric: 63 A
  • Interrupt Rating: 200 kAIC at 300 Vdc, 50 kAIC at 300 Vdc
  • Class: Class aR
  • Color: White
  • Connection: Ferrule end X ferrule end
  • Construction Size: 22 x 58 mm
  • Material Type: Ceramic
  • Packaging Type: Standard
  • Diameter: 22 MM
  • Quantity: 10
  • Used With: Finger safe holders/blocks and striker
  • Breaking Capacity: 200 A
  • Clearing (I2T): 4000
  • Frequency Rating Maximum: 62 HZ
  • Frequency Rating Minimum: 45 HZ
  • Fuse Shape: cylindrical
  • Fuse Indicator: Non Indicating
  • Minimum Melting: 280 I2t (A2 Sec)
  • Pre Arc (I2T): 280
  • Release Characteristic: Other
  • Utilization category: aR (accompanied semiconductor protection)
  • Voltage Type: AC/DC
  • Watt Losses: 15
  • With Striker: No

Overview

UPC 05171279657
Item Long Description Eaton Bussmann series FWP high speed fuse, 700 Vac, 700 Vdc (UL), 63A, 200 kAIC at 300 Vdc, 50 kAIC at 300 Vdc, Non Indicating, High speed fuse, Ferrule end X ferrule end, Class aR, White, Ceramic
GTiN 00051712796576
Length 58 mm
Width 22 mm
Size 0.875 In Diameter X 2.283 In Length
Color White
Voltage 700 Volt
Type Fuse
Diameter 22 mm
Applications Ind Facilities & Factories - Facility: Safety and Security SystemsInd Facilities & Factories - Facility: Critical PowerElec Assemblies, Panels & EOEM - Electrical Assemblies and EOEMs - OtherElec Assemblies, Panels & EOEM - Electrical Assemblies, Panels and EOEMs
Height 22 mm
Weight 62.6 g
Standard CE,UL
Connection Type Ferrule
Family Brand Name Bussmann Series
Class Class AR
TC Connection Ferrule end X ferrule end
Amperage 63 Amp
End Type Ferrule
Interrupt Rating 200 kA
Blade Dimensions 2.2835 IN X 0.8661 IN X 0.8661 IN
Sub Brand Bussmann Series
