BUSS FWP-80A22FI 80A 700V 22X58 IND
$123.26/ea
Usually ships within 6 to 8 Days
ea
Adding...
Already a Customer? Log in to view your pricing
Manufacturer Cooper / Bussman
Mfg Catalog # FWP-80A22FI
North Coast Part # 675644

Specifications

  • Interrupt Rating: 200 kAIC at 300 Vdc, 50 kAIC at 300 Vdc
  • Release Characteristic: Other
  • Amperage Rating: 80A
  • Frequency Rating Maximum: 62 HZ
  • Amperage Rating Numeric: 80 A
  • Fuse Size: 22 x 58 mm
  • With Striker: Yes
  • Voltage Rating: 690V (IEC), 700V (UL)
  • Diameter: 22 MM
  • Fuse Indicator: With Indicator
  • Construction Size: 22 x 58 mm
  • Clearing (I2T): 7800
  • Color: White
  • Connection: Ferrule end X ferrule end
  • Quantity: 10
  • Material Type: Ceremic
  • Utilization category: aR (accompanied semiconductor protection)
  • Watt Losses: 15
  • Type: High speed fuse
  • Used With: Finger safe holders/blocks and striker
  • Fuse Shape: cylindrical
  • Breaking Capacity: 200 A
  • Frequency Rating Minimum: 45 HZ
  • Class: Class aR
  • Pre Arc (I2T): 550
  • Application: protection of DC common bus, DC drives, power converters/rectifiers and reduced voltage starters
  • Voltage Rating Numeric: 700 V
  • Voltage Type: AC/DC
  • Packaging Type: Standard

General

  • UPC: 051712542845
  • EAN: 5027590501118
  • Product Length/Depth: 58 MM
  • Product Height: 22 MM
  • Product Width: 22 MM
  • Product Weight: 63.4 G
  • Warranty: Not Applicable
  • Compliances: CE Marked
  • Certifications: UL Recognized

Overview

UPC 05171254284
GTiN 00051712542845
Length 58 mm
Width 23 mm
Size 0.875 In Diameter X 2.283 In Length
Color White
Type High Speed Fuse
Diameter 22 mm
Applications Ind Facilities & Factories - Facility: Safety and Security SystemsInd Facilities & Factories - Facility: Critical PowerElec Assemblies, Panels & EOEM - Electrical Assemblies and EOEMs - OtherElec Assemblies, Panels & EOEM - Electrical Assemblies, Panels and EOEMs
Height 22 mm
Weight 63.4 g
Connection Type Ferrule
Family Brand Name Eaton
TC Connection Ferrule end X ferrule end
Amperage 80 Amp
End Type Ferrule
Interrupt Rating 200 kA
Class Class aR
Blade Dimensions 2.2835 IN X 0.8661 IN X 0.8661 IN
Sub Brand Bussmann Series
Voltage 690 Volt
Standard CE,UL
