Bussmann Series FWX-30A14F 30 Amp 250 VAC/VDC Ferrule Semiconductor High Speed Fuse
Product image thumbnail 0
Product image thumbnail 1
Product image thumbnail 2
Product image thumbnail 3
$31.52/ea
Usually ships within 6 to 8 Days
ea
Adding...
Already a Customer? Log in to view your pricing
Manufacturer Cooper / Bussman
Mfg Catalog # FWX-30A14F
North Coast Part # 161836

Specifications

  • Height: 14 MM
  • Length: 51 MM
  • Width: 14 MM
  • Weight: 21.4 G
  • Type: Fuse
  • Application: protection of DC common bus, DC drives, power converters/rectifiers and reduced voltage starters
  • Voltage Rating: 600V
  • Voltage Rating Numeric: 250 V
  • Amperage Rating: 30A
  • Amperage Rating Numeric: 30 A
  • Interrupt Rating: 200 kAIC Vac, 50 kAIC at 250 Vdc
  • Connection: Ferrule end X ferrule end
  • Construction Size: 14 x 51 mm
  • Packaging Type: Standard
  • Breaking Capacity: 200 A
  • Clearing (I2T): Clearing at 250V: 500
  • Frequency Rating Maximum: 62 HZ
  • Frequency Rating Minimum: 45 HZ
  • Fuse Shape: cylindrical
  • Fuse Indicator: Non Indicating
  • Pre Arc (I2T): 100
  • Release Characteristic: Other
  • Utilization category: aR (accompanied semiconductor protection)
  • Voltage Type: AC/DC
  • Watt Losses: 5.9W
  • With Striker: No

Categories

Overview

UPC 05171279560
Item Long Description Eaton Bussmann series FWX high speed fuse, 600V, 30A, 200 kAIC Vac, 50 kAIC at 250 Vdc, Non Indicating, High speed fuse, Ferrule end X ferrule end
GTiN 00051712795609
Length 51 mm
Width 14 mm
Size 0.563 In Diameter X 2.000 In Length
Voltage 600 Volt
Type Fuse
Applications Ind Facilities & Factories - Facility: Safety and Security SystemsElec Assemblies, Panels & EOEM - Electrical Assemblies and EOEMs - OtherInd Facilities & Factories - Facility: Critical PowerElec Assemblies, Panels & EOEM - Electrical Assemblies, Panels and EOEMs
Height 14 mm
Weight 21.4 g
Connection Type Ferrule
Family Brand Name Bussmann Series
TC Connection Ferrule end x ferrule end
Amperage 30 Amp
End Type Ferrule
Interrupt Rating 200 kA
Blade Dimensions 2.0079 IN X 0.5512 IN X 0.5512 IN
Sub Brand Bussmann Series
