Bussmann Series LP-CC-6/10 Low Peak Time Delay Fuse
Product image thumbnail 0
Product image thumbnail 1
$25.91/ea
Usually ships within 6 to 8 Days
ea
Adding...
Already a Customer? Log in to view your pricing
Manufacturer Cooper / Bussman
Mfg Catalog # LP-CC-6/10
North Coast Part # 18535

Specifications

  • Height: 1.5 IN
  • Length: .41 IN
  • Width: .41 IN
  • Weight: .15 LB
  • Type: Current-limiting, Time-delay
  • Special Features: Rejection Style
  • Application: Specialized circuits and industrial control
  • Voltage Rating: 600 Vac, 300 Vdc
  • Amperage Rating: 0.60A
  • Interrupt Rating: 200 kAIC at 600 Vac, 20 kAIC at 150 Vdc
  • Class: Class CC
  • Connection: Ferrule end X ferrule end
  • Material Type: Melamine tube
  • Packaging Type: Standard
  • Diameter: .40625 IN
  • Quantity: Carton: 10
  • Fuse Indicator: Non Indicating
  • Response Time: 12s at 200%
  • Number Of Elements: Dual

Overview

UPC 05171218041
GTiN 00051712180412
Length .41 in
Width .41 in
Size 13/32 In Diameter X 1-1/2 In Length
Voltage 300 Volt
Type Current Limiting,Time-Delay
Diameter .406 in
Material Melamine tube
Applications Ind Facilities & Factories - Facility: Safety and Security Systems
Height 1.5 in
Weight .15 lb
Connection Type Ferrule
Family Brand Name Bussmann Series
Class CC
TC Connection Ferrule end x ferrule end
Amperage 0.6 Amp
Response Time 12 S at 200%
End Type Ferrule
Interrupt Rating 20 kA
Sub Brand Bussmann Series
Blade Dimensions 1.5000 IN X 0.4100 IN X 0.4100 IN
