Manufacturer Cooper / Bussman
Mfg Catalog # TB100-10SP
North Coast Part # 1344219


  • Mounting: Screw
  • Special Features: Breakdown voltage 3600V
  • Type: Double row, barrier
  • Color: Black
  • Connection: #6-32 TPI Screw
  • Material: Tin-plated brass terminal, Zinc-plated Steel SEMS philslot screw
  • Operating Temperature: -40° to 130°C
  • Voltage Rating: 300V
  • Amperage Rating: 30A
  • Torque Rating: 9 lb-in
  • Number Of Poles: Ten-pole


  • UPC: 051712193863
  • Product Length/Depth: 2.16 IN
  • Product Height: .41 IN
  • Product Width: .88 IN
  • Product Weight: .43 LB
  • Warranty: Not Applicable
  • Compliances: CE Marked
  • Certifications: Contact Manufacturer


UPC 05171219386
Item Long Description Double Row Terminal Block, 30A, Black, #6-32 TPI Screw, Screw, Ten-pole, -40 to 130 Degrees C, Breakdown voltage 3600V, Double row, barrier, 300V, Tin-plated brass terminal, Zinc-plated Steel SEMS philslot screw, 9 lb-in
GTiN 00051712193863
Length 2.16 in
Width .88 in
Color Black
Operating Temperature -40 To 130 C
Voltage 300 Volt
Type Barrier,Double Row
Material Zinc-Plated Steel
Mounting Type Screw
Height .41 in
Weight .43 lb
Threads Per Inch 32
Screw Size #6
Connection Type Screw
Family Brand Name Eaton
Amperage 30 Amp
Number of Poles 10
Applications Stationary Mach Equip In Factory - Robotics
Blade Dimensions 2.1600 IN X 0.8800 IN X 0.4100 IN
