Crouse-Hinds Series E1016-1727 600 VAC/VDC 2 to 4/0 AWG Red Elastomeric Double Set Screw Female Receptacle
Product image thumbnail 0
Product image thumbnail 1
Product image thumbnail 2
Product image thumbnail 3
$124.09/ea
Usually ships within 8 to 12 Days
ea
Adding...
Already a Customer? Log in to view your pricing
Manufacturer Cooper / Crouse-Hinds
Mfg Catalog # E1016-1727
North Coast Part # 426510

Specifications

  • Cable Size: 1/0-4/0 AWG
  • Amperage Rating: Up to 400A Continuous
  • Voltage Rating: 600 Vac/dc
  • Material: Thermoplastic elastomer (TPE)
  • Connection Type: Double set screw
  • Gender: Female
  • Color: Red

General

  • UPC: 662275129284
  • Product Length/Depth: 4.25 IN
  • Product Height: 2.25 IN
  • Product Width: 2.25 IN
  • Product Weight: 1 LB

Certifications And Compliances

  • Area Classification: Ordinary/Non-Hazardous Locations
  • Standards Type: NEC/CEC
  • NEMA Rating: 3R

Categories

Overview

UPC 66227512928
Family Brand Name Crouse-Hinds Series
Item Long Description Eaton Crouse-Hinds series Cam-Lok J Series E1016 insulated receptacle, Up to 400A continuous, 1/0-4/0 AWG, Red, Double set screw, Female, Thermoplastic elastomer (TPE), 600 Vac/dc
GTiN 00662275129284
Length 4.25 in
Width 2.25 in
Size 4.25 In Length X 2.25 In Width X 2.25 In Height
Color Red
Voltage 600 Volt
Type Female
Insulation Type TPE
Material Thermoplastic Elastomer (TPE)
Applications Quick Disconnect Power Systems Indoor/Outdoor
Height 2.25 in
Weight 1 lb
Wire Size 2-0000 AWG
Standard UL,CSA
Connection Type Double Set Screw
Temperature Rating -40 to 105 C
TC Connection Double Set Screw
Amperage 400 Amp
Environmental Conditions -40 to 105 C
Number of Poles 1 Pole
Sub Brand Cam-Lok
