Arrow Hart Wiring AHL1830P 30 Amp 120/208 VAC 3-Phase 4-Pole 4-Wire NEMA L18-30 Black/White Locking Plug
Product image thumbnail 0
Product image thumbnail 1
$86.17/ea
Usually ships within 11 to 17 Days
ea
Adding...
Already a Customer? Log in to view your pricing
Manufacturer Cooper Wiring Devices
Mfg Catalog # AHL1830P
North Coast Part # 1685127

Specifications

  • Special Features: Locking flanged outlet
  • Color: Black, white
  • Face/Body Material: Nylon
  • Wiring Method: Back
  • Material: Nylon
  • Allowable Wire Size: #16-8 AWG
  • Amperage Rating: 30A
  • Number Of Poles: Three-pole
  • Contact Material: Brass
  • Type: Locking plug
  • Device Grade: Extra heavy duty industrial specification grade
  • Nema Configuration: L18-30
  • Design Type: Ultra grip
  • Number Of Wires: Four-wire, grounding
  • Operating Temperature: -40°C to 60°C (-40°F to 140°F)
  • Voltage Rating: 3ØY 120/208 V
  • Cord Diameter: 0.38-1.16in (9.5-29.4mm)
  • Application: Industrial

General

  • UPC: 032664738142
  • Product Length/Depth: 4.19 IN
  • Product Height: 2.31 IN
  • Product Width: 2.28 IN
  • Product Weight: .4 LB
  • Warranty: Refer to warranty document.
  • Compliances: RoHS Compliant
  • Certifications: NOM

Categories

Overview

UPC 03266473814
Family Brand Name Eaton
Item Long Description Eaton locking plug, #16-8 AWG, 30A, Industrial, 120/208V, Back wiring, Black, white, Ultra grip, L18-30, Three-pole, Four-wire, Nylon
GTiN 00032664738142
Length 4.19 in
Color Black,White
Operating Temperature -40 To 140 F
Voltage 120/208 Volt
Type Locking Plug
Material Nylon
Applications LOCKING DEVICES
Height 2.31 in
Weight .4 lb
Amperage 30 Amp
Number of Poles 3 Pole
Number of Wires 4
Sub Brand Eaton Wiring Devices
Size 3
Wire Size 16-12 AWG
Cord Range 0.63 - 1.16 in
Connection Type Screw
NEMA L18-30
Number of Phases 2 Phase
Environmental Conditions -40 To 60 C
