Usually ships within 11 to 17 Days
Already a Customer? Log in to view your pricing
Manufacturer Greenlee
Mfg Catalog # EK12IDLX120
North Coast Part # 1345406


  • Equipped with Bluetoothâ„¢ Communication enabled via the Greenlee Gator Eye app
  • Features LED display screen communicating pressure and battery levels as well as tool diagnostics with real-time tool feedback
  • Intelligent Crimping System Technology includes a pressure sensor that monitors the crimping force of each crimp and provides the operator a visual and audible alert if the force is below specifications
  • State of the art 18V lithium ion (Li-ion) battery provides 70% more cycles per charge and faster cycle times
  • Automatic Retraction Stop (ARS) which retracts the ram just enough to get ready for the next cycle saving time and energy
  • LED light provides the operator with the battery charge and tool maintenance status
  • Two-stage hydraulic system provides fast advance and power speeds, saving time
  • Forward handle position improves tool balance
  • One trigger controls all tool functions
  • Crimping head rotates 350°
  • Tools automatically retract when the crimping cycle is complete
  • Overmolded tacky grip areas make gripping the tool easier and more comfortable
  • LED work light illuminates dark work areas
  • Greenlee battery-powered crimping tools now use bio-degradable oil
  • Smart chargers control the charging current, charging voltage and battery temperature to maximize battery life
  • Flip open crimping head will allow crimping of 4 AWG-1000 kcmil copper or 6 AWG-1000 kcmil aluminum with no dies to change
  • Available with 120V, 12V or 230V battery charger or with 120V or 230V corded adapter in place of batteries and charger


  • Sub Brand: Gator
  • Type: Dieless style crimper
  • Application: 12 Ton Crimping
  • Standard: C/US UL Listed
  • Wire Size: 6 AWG - 1000 kcmil Al
  • Overall Length: 16.5 IN (420mm)
  • Crimping Force: 24,000 lbs. (106 kN)
  • Crimping Capacity: 1000 Kcmil (MCM) Cu & Al
  • Connector Type: Color-coded lugs and splices
  • Handle Type: Pistol Style with over molded rubber grip


GTiN 00783310611370
Type Dieless Style Crimper
Connector Type Color-coded lugs and splices
Applications 12 Ton Crimping
Wire Size 6 AWG-1000 kcmil (AL)/4 AWG-1000 kcmil (CU)
Crimping Force 24,000 lb
Standard C/US UL Listed
Handle Type Pistol Style with over molded rubber grip
Family Brand Name Greenlee
Overall Length 16.5 in
Sub Brand Gator
Product UPC 78331061137
