Hoffman A10106SC 10 x 10 x 6 Inch 14 Gauge Painted Steel NEMA 12 Screw Cover Junction Box
$168.50/ea
Usually ships within 6 to 8 Days
ea
Adding...
Already a Customer? Log in to view your pricing
Manufacturer Hoffman Engineering
Mfg Catalog # A10106SC
North Coast Part # 603839

Features

  • 16 or 14 gauge steel
  • Seams continuously welded and ground smooth
  • Bonding provision on cover
  • Oil-resistant gasket
  • Weldnuts provided for mounting optional panels and terminal block kits in size 6.00 x 4.00 in. (152 x 102 mm) and larger
  • External wall-mounting brackets for easy installation

Notes

  • Purchase panels separately. Optional stainless steel, conductive, composite and aluminum panels are available for most sizes.

Accessories

  • Panels for Junction Boxes
  • Junction Box and Wall-Mount Enclosure Swing Out Panel Kit
  • Terminal Block Kit Assembly for Junction Boxes Overview
  • Steel and Stainless Steel Window Kits

Specifications

  • Bulletin Number: A51SC
  • Material: Steel
  • Model Code: 54250
  • Ship Wt. Std. Pkg. (lbs): 44.0
  • Interchangeable: False
  • Finish: ANSI 61
  • UL Listed: 50, 50E
  • Catalog Number: A10106SC
  • A in.: 10
  • B in.: 10
  • C in.: 6
  • K in.: 0.67
  • F in.: 5.53
  • Panel Size D x E in.: 8.75 x 8.88
  • Gauge: 14
  • J in.: 5.51
  • Conductive Panel: A10P10G
  • V in.: 0.25
  • T in.: 9.00
  • Overall L x W in.: 11.50 x 10.28
  • Mounting G x H in.: 10.75 x 8.00
  • Y in.: 0.62
  • Panel: A10P10
  • Standards: UL 50, 50E Listed; Type 12, 13; File No. E27525 || cUL Listed per CSA C22.2 No. 94; Type 12, 13; File No. E27525 || UL 508A Listed; Type 12, 13; File No. E61997 || cUL Listed per CSA C22.2 No. 94; Type 12, 13; File No. E61997 || NEMA/EEMAC: Type 12 and 13 || CSA, File No. 42184: Type 12 || IEC 60529, IP65

Overview

UPC 78351054250
GTiN 00783510542504
Finish ANSI 61
Width 10 in
Size 10.00x10.00x6.00 in
Color Gray
Type Screw Cover
Material Steel
Applications Controls and Drives
Depth 6 in
Height 10 in
Standard 13,50E Listed,CSA,CUL Listed Per CSA C22.2 No. 94,F,File No. E27525,File No. E61997,NEMA/EEMAC: Type 12 And 13,Type 12,UL 50,UL 508A Listed
Family Brand Name Hoffman
Gauge 14 AWG
Sub Brand Hoffman
