Hoffman A14086CH 14 x 8 x 6 Inch Gray 14 Gauge Steel NEMA 12 Junction Box
Product image thumbnail 0
Product image thumbnail 1
Product image thumbnail 2
$190.82/ea
Usually ships within 6 to 8 Days
ea
Adding...
Already a Customer? Log in to view your pricing
Manufacturer Hoffman Engineering
Mfg Catalog # A14086CH
North Coast Part # 155140

Features

  • Seams continuously welded and ground smooth
  • Continuous hinge
  • Screw-down door clamps
  • Bonding provision on door
  • External wall-mounting brackets for easy installation
  • Oil-resistant gasket
  • Weldnuts provided for mounting optional panels and terminal block kits in size 6.00 x 4.00 in. (152 x 102 mm) and larger

Specifications

  • Height (H) (inch): 14
  • Height (H) (millimetre): 356
  • Width (W) (inch): 8
  • Width (W) (millimetre): 203
  • Depth (D) (inch): 6
  • Depth (D) (millimetre): 152
  • Protection Rating: NEMA Type 12
  • Material: Mild Steel
  • NEMA Rating: 12 Indoor, dust-resistant
  • Panel Size (D x E) (inch): 12.75 x 6.88
  • Panel Size (D x E) (millimetre): 324 x 175
  • Conductive Panel: A14P8G
  • Overall Dimensions (L x W) (inch): 15.50 x 8.94
  • Overall Dimensions (L x W) (millimetre): 394 x 227
  • Mounting (G x H) (inch): 14.75 x 6.00
  • Mounting (G x H) (millimetre): 375 x 152
  • Panel: A14P8
  • Modification Services: Yes
  • Type Number: Type 13
  • IP Rating: IP65
  • Color: Gray
  • Color Code: ANSI 61
  • Finish: Powder Coated
  • Thickness (T) (gauge): 14
  • Thickness (T) (millimetre): 1.9
  • Size: 14.00x8.00x6.00 in

Related Products

Accessory

  • A14P8
  • AL23SS
  • APLKJIC
  • APLKJIC6SS
  • AL18
  • AJCDFK
  • A8JTMA
  • A14P8G
  • A8JS
  • A8JBNS
  • A14JTMA
  • A14JS
  • A14JBNS
  • AS050

Categories

Overview

UPC 78351055450
Item Long Description This easy-to-open, continuous hinge enclosure features screw-down clamps for secure closure and can be used in a wide variety of applications.
GTiN 00783510554507
Finish Powder Coated
Width 203 mm
Size 14.00x8.00x6.00 in
Color Gray
Type Two Lock, Single Door
Material Steel
Applications This Easy-to-Open, Continuous Hinge Enclosure Features Screw Down Clamps for Secure Closure and can be used in a Wide Variety of Applications. Suitable for Metrical Mounting
Mounting Type Wall
Depth 152 mm
Height 356 mm
Standard 13,50E Listed,CSA,CUL Listed Per CSA 22.2 No. 94,File,File No. E27567,File No. E61997,NEMA/EEMAC Type 12 And 13,Type 12,UL 50,UL 508A Listed
Family Brand Name Hoffman
Gauge 14 and 16
Cover Type Continuous Hinged with Clamp
Sub Brand Hoffman
Thickness 1.9 mm
