Hoffman A606LP 6 x 6 x 4 Inch 16 Gauge Steel NEMA 12 Lift-Off Clamp Cover Junction Box
Product image thumbnail 0
Product image thumbnail 1
Product image thumbnail 2
$89.43/ea
Usually ships within 6 to 8 Days
ea
Adding...
Already a Customer? Log in to view your pricing
Manufacturer Hoffman Engineering
Mfg Catalog # A606LP
North Coast Part # 157075

Features

  • Seams continuously welded and ground smooth
  • Screw-down clamps
  • Lift-off cover
  • Bonding provision on cover
  • Chain holds cover to box when cover is removed
  • Oil-resistant gasket
  • Weldnuts provided for mounting optional panels and terminal block kits in size 6.00 x 4.00 in. (152 x 102 mm) and larger
  • External wall-mounting brackets

Specifications

  • Height (H) (inch): 6
  • Height (H) (millimetre): 152
  • Width (W) (inch): 6
  • Width (W) (millimetre): 152
  • Depth (D) (inch): 4
  • Depth (D) (millimetre): 102
  • Protection Rating: NEMA Type 12
  • Material: Mild Steel
  • NEMA Rating: 12 Indoor, dust-resistant
  • Conductive Panel: A6P6G
  • Panel: A6P6
  • Panel Size (D x E) (inch): 4.88 x 4.88
  • Panel Size (D x E) (millimetre): 124 x 124
  • Mounting (G x H) (inch): 6.75 x 4.00
  • Mounting (G x H) (millimetre): 171 x 102
  • Overall Dimensions (L x W) (inch): 7.50 x 6.57
  • Overall Dimensions (L x W) (millimetre): 191 x 167
  • Modification Services: Yes
  • Type Number: Type 13
  • IP Rating: IP65
  • Color: Gray
  • Color Code: ANSI 61
  • Finish: Powder Coated
  • Thickness (T) (gauge): 16
  • Thickness (T) (millimetre): 1.52
  • Size: 6.00x6.00x4.00 in

Related Products

Accessory

  • A6P6
  • AL23SS
  • A6P6AL
  • APLKJIC
  • A6P6G
  • AL23
  • APLKJIC6SS
  • AL18
  • A6P6SS
  • AL17
  • A6JTMA
  • A6P6C
  • AS050

Categories

Overview

UPC 78351054050
Item Long Description With a chain-secured, lift-off clamp cover, this enclosure meets basic functionality requirements for housing controls and instrumentation.
GTiN 00783510540500
Finish Polyester Powder Painted
Width 152 mm
Size 6.00x6.00x4.00 in
Color Gray
Type Single Door, Four Lock
Material Steel
Applications For Use with a Chain-secured, Lift-Off Clamp Cover, This Enclosure Meets Basic Functionality Requirements for Housing Controls and Instrumentation
Depth 102 mm
Height 152 mm
Standard CSA, File No. 42184: Type 12,CUL Listed Per CSA C22.2 No. 94; Type 12, 13; File No. E27525,CUL Listed Per CSA C22.2 No. 94; Type 12, 13; File No. E61997,IEC 60529, IP65,NEMA/EEMAC Type 12 And 13,UL 50, 50E Listed; Type 12, 13; File No. E27525,UL 508A Listed; Type 12, 13; File No. E61997
Family Brand Name Hoffman
Gauge 16 AWG
Sub Brand Hoffman
Mounting Type Wall
Thickness 1.52 mm
