Hoffman A60R5224FSLP 60 x 52 x 24 Inch Steel Pad Mount Two Door Enclosure
Product image thumbnail 0
Product image thumbnail 1
Product image thumbnail 2
$2,088.64/ea
Usually ships within 6 to 8 Days
ea
Adding...
Already a Customer? Log in to view your pricing
Manufacturer Hoffman Engineering
Mfg Catalog # A60R5224FSLP
North Coast Part # 271569

Features

  • 3-point latching system with heavy duty handle
  • Padlock provision in handle
  • Open bottom with pre-punched mounting hole flange
  • Drip edge overhang on top
  • Louvered overhang with a closure plate
  • Studs included for mounting optional panels on threaded bolts
  • Welded body construction
  • Sturdy 7 gauge lifting tabs
  • Overlapping doors with no center post on two-door models
  • Bonding provision on each door

Specifications

  • Height (H) (inch): 60
  • Height (H) (millimetre): 1,524
  • Width (W) (inch): 52
  • Width (W) (millimetre): 1,321
  • Depth (D) (inch): 24
  • Depth (D) (millimetre): 610
  • Protection Rating: NEMA Type 3R
  • Material: Mild Steel
  • NEMA Rating: 3R Weather-resistant, except dust
  • Panel Size (D x E) (inch): 49.16 x 48.00
  • Panel Size (D x E) (millimetre): 1249 x 1219
  • Panel: A49P48N
  • Mounting Dimensions (F x G) (inch): 7.90 x 20.90
  • Mounting Dimensions (F x G) (millimetre): 201 x 531
  • Modification Services: Yes
  • Type Number: Type 3R
  • IP Rating: IP32
  • Color: Light Gray
  • Color Code: RAL 7035
  • Finish: Galvanized
  • Thickness (T) (gauge): 14
  • Thickness (T) (millimetre): 1.9
  • Sub Brand: WeatherPro
  • Size: 60.00x52.00x24.00 in

Related Products

Accessory

  • A3PMIS

Categories

Overview

UPC 78351014424
Item Long Description WeatherPro Outdoor Pad Mount Enclosures protect controls, drives, power distribution components or contactors in outdoor commercial or industrial power distribution and control applications. The overlapping two-door models with no center post allow full-width access to enclosure interior.
GTiN 00783510144241
Finish Polyester Textured Powder Coated
Width 52 in
Size 60.00x52.00x24.00 in
Color RAL 7035 Light Gray
Type Outdoor, Free-Stand
Material Steel
Applications Controls and Drives; Power Distribution
Depth 24 in
Height 60 in
Standard CUL/CSA C22.2 No. 94 Listed; Type 3R; File No. E61997,IEC 60529, IP32Catalog Weights & Dimensions Are Careful Estimates But Not Guaranteed.,NEMA/EEMAC Type 3R,UL 508A Listed; Type 3R; File No. E61997
Family Brand Name Hoffman
Sub Brand Weatherpro
Mounting Type Pad
Gauge 14
Thickness 1.9 mm
