NVENT HOF A726036SSFSDN4 TWO DOOR F
Product image thumbnail 0
Product image thumbnail 1
$21,630.68/ea
Usually ships within 6 to 8 Days
ea
Adding...
Already a Customer? Log in to view your pricing
Manufacturer Hoffman Engineering
Mfg Catalog # A726036SSFSDN4
North Coast Part # 1164007

Features

  • Seams continuously welded and ground smooth; no holes or knockouts
  • Two-door enclosures provided with a removable centerpost for easy panel installation
  • Heavy-duty lifting eyes are Type 316L stainless steel
  • Heavy-duty three-point latching mechanism operated by Type 316L stainless steel PowerGlide padlocking handle
  • Seemless foam-in-place gasket assures a water-tight and dust-tight seal
  • Body flange trough collar excludes liquids and contaminants
  • Heavy-gauge continuous hinges support each door
  • High-impact thermoplastic data pocket provided with each enclosure
  • Mounting channels welded horizontally to interior body sides at top, bottom and center
  • Optional panels and rack mounting angles can be mounted anywhere along channels

Specifications

  • Height (H): 1,830 millimetre
  • Width (W): 1,526 millimetre
  • Depth (D): 916 millimetre
  • Protection Rating: NEMA Type 4X
  • Material: Stainless Steel 304
  • NEMA Rating: 4X Watertight, corrosion-resistant
  • Modification Services: Yes
  • Type Number: Type 3R
  • IP Rating: IP66
  • Color: Unpainted
  • Finish: Brushed #4
  • Thickness (T): 2.78 millimetre

Related Products

Accessory

  • AS050SS
  • G280416G051
  • A72P60F2G
  • A72P30F1
  • A72P60F1G
  • A72P60F1
  • A72P30F2
  • A72P30F2G
  • A72P30F1G
  • A72P60F2
  • A72SP30F3
  • A72SP30F4
  • A72SMP20G
  • A72SMP14G
  • A72SMP14
  • A72SMP20
  • A72FSHDPS
  • A72FSCPS
  • APS1420CN
  • APS51618CN
  • DMCKC
  • P19RP6UA
  • P19RP1UA
  • P19RP3UA
  • P19RP4UA
  • P19RP11UA
  • P19RP2UA
  • P19RP10UA
  • P24RP8UA
  • P19RP12UA
  • P24RP2UA
  • P19RP9UA
  • P19RP7UA
  • P19RP5UA
  • P19RP8UA
  • P24RP4UA
  • P24RP5UA
  • A72RP30F6
  • A72RP30F5
  • A72RA24TH
  • AN1032
  • A7230SOF19
  • LED24V15
  • LED24VCORD
  • AEKDF
  • AEK115NDH
  • GSKTKITS375
  • ADPX4CSS
  • ADPX4BSS
  • ADPX4ASS
  • HGF5USBUSBSS
  • HDP5USBUSBSS
  • HGF5ETHETHSS
  • HDP5ETHETHSS

Overview

UPC 78351011182
GTiN 00783510111823
Width 60.06 in
Size 72.06x60.06x36.06 in
Type Two Door, Single Access
Material 304 Stainless Steel
Applications For Automotive, Pulp and Paper, Wood Products, Textile Industries
Depth 36.06 in
Height 72.06 in
Standard CUL Listed Per CSA C22.2 No 94; Type 3R, 4, 4X, 12; File No. E61997,E.I.A. RS-310-D,IEC 60529, IP66,NEMA/EEMAC Type 3, 3R, 4, 4X, 12, 13,UL 508A Listed; Type 3R, 4, 4X, 12; File No. E61997
Family Brand Name Hoffman
Sub Brand Hoffman
Finish Brushed
Mounting Type Free-Standing
Gauge 12
Cover Type Continuous Hinged with 3-Point Latch and Padlocking Handle
Thickness 2.78 Millimetre mm
