HOFF-E A72XD4018FTCLPG One Door Seq
$4,000.00/ea
Usually ships within 6 to 8 Days
ea
Adding...
Already a Customer? Log in to view your pricing
Manufacturer Hoffman Engineering
Mfg Catalog # A72XD4018FTCLPG
North Coast Part # 936318

Features

  • Interlocks doors of main control cabinet when disconnect switch is powered ON
  • Mechanical interlock on main control enclosure activated by master door prevents slave door from being opened first
  • Provision for pass-through power into the main enclosure
  • Preferred disconnect cutout
  • Quarter-turn, screwdriver slot latch on Sequestr Enclosure
  • Rugged PowerGlide Handle with three-point latch on main control enclosure
  • Concealed, easy-to-remove hinges
  • Grounding studs on body
  • Bonding provision on door
  • Conductive back panel included in Sequestr External Disconnect Enclosure
  • Optional back panel for main control cabinet for maximum ordering flexibility
  • Sequestr External Disconnect Enclosure is shipped unattached for easy disconnect installation
  • A28X base enclosure
  • A70D external disconnect enclosure
  • External disconnect enclosure .060-in. steel; main control cabinet .121-in. steel
  • Continuously welded and ground seams all around
  • Body flange trough excludes liquids and contaminants
  • Heavy duty lifting eyes anchored into reinforced top
  • Removable centerposts for easy back panel installation
  • No disconnect cutout on main control cabinet

Notes

  • 1) B dimension is large enclosure without External Disconnect Enclosure. 2) B2 dimension is overall size including External Disconnect Enclosure. 3) Purchase panels separately.

Accessories

  • Industrial Corrosion Inhibitors
  • Floor Stand Kit
  • PaneLite Enclosure Lights Overview

Specifications

  • Bulletin Number: Steel
  • Material: 25773
  • Model Code: 534.0
  • Ship Wt. Std. Pkg. (lbs): False
  • Catalog Number: A72XD4018FTCLPG
  • A in.: 72.12
  • B in.: 40.25
  • C in.: 18.12
  • D in.: 0
  • Description: Standard Product: One-Door Enclosure
  • Panel Size in.: 60.00 x 33.75
  • B2 in.: 54.25
  • Panel: A72PM40
  • Interior Finish: Gray
  • Standards: UL 508A Listed; Type 12; File No. E61997 || cUL Listed per CSA C22.2 No. 94; Type 12; File No. E61997 || NEMA/EEMAC Type 12 || CSA File No. 42186: Type 12 || IEC 60529, IP55

Overview

UPC 78351025773
GTiN 00783510257736
Finish Gray
Width 40.25 in
Size 72.12x40.25x18.12 in
Type SEQUESTR External Disconnect Package, Type 12
Material 25773
Applications The SEQUESTR External Disconnect Enclosure Package helps mitigate arc flash occurrences when working on interior components by isolating incoming power from the main enclosure. Shipped as one unit for new installations, the disconnect switch and fuse block/circuit breaker are mounted in the external enclosure, with terminal connections to bring power to the main enclosure.
Depth 18.12 in
Height 72.12 in
Family Brand Name Hoffman
Sub Brand Sequestr
