ONE DOOR TY 4 DISC ENC W 3PT
Product image thumbnail 0
Product image thumbnail 1
Product image thumbnail 2
$4,275.00/ea
Usually ships within 6 to 8 Days
ea
Adding...
Already a Customer? Log in to view your pricing
Manufacturer Hoffman Engineering
Mfg Catalog # A84XM4018FTCLP4
North Coast Part # 1343455

Features

  • Quick-release continuous hinge
  • Seams continuously welded and ground smooth
  • Body stiffeners in larger enclosures for extra rigidity
  • Body flange trough excludes liquids and contaminants
  • Heavy-duty lifting eyes anchor into reinforced top
  • Removable centerposts permit easy panel installation
  • Heavy-duty 3-point latching mechanism operated by padlocking handle on all doors
  • Ends of latch rods have rollers for easier door closing
  • Panel supports

Specifications

  • Height (H) (inch): 84.12
  • Height (H) (millimetre): 2,137
  • Width (W) (inch): 40.25
  • Width (W) (millimetre): 1,022
  • Depth (D) (inch): 18.12
  • Depth (D) (millimetre): 460
  • Protection Rating: NEMA Type 4
  • Material: Mild Steel
  • NEMA Rating: 4 Watertight
  • Painted Panel: A84PM40
  • Conductive Panel: A84PM40G
  • Modification Services: Yes
  • Type Number: Type 3R
  • IP Rating: IP66
  • Color: Gray
  • Color Code: ANSI 61
  • Finish: Powder Coated
  • Thickness (T) (gauge): 11
  • Thickness (T) (millimetre): 3.04
  • Size: 84.12 x 40.25 x 18.12 in

Related Products

Accessory

  • A84PM40G
  • A84PM40
  • APWK95NF
  • APWK1711NF
  • APWK3024H
  • APWK2315NF
  • AWDH3624N4
  • APWK2016H
  • APWK2919NF
  • APWK2420H
  • AWDH1418N4
  • APWK1212H
  • AWDH3024N4
  • AWDH2430N4
  • APWK138NF
  • AWDH2416N4
  • AWDH1612N4
  • APWK3523NF
  • APWK175NF
  • APWK53NF
  • APWK2020H
  • APWK133NF
  • AWDH2016N4
  • APWK1612H
  • AWDH2420N4
  • APCCHVA
  • ADPX4A
  • ADPX4ALG
  • ADPX4CLG
  • APCSDA
  • APCABVA
  • ADPX4B
  • GSKTKITS375
  • ADPX4BLG
  • APCITE
  • ALFSWD
  • UBP
  • APCGETDA
  • ADPX4C
  • DLGP610
  • GP2412
  • GP126
  • AA61SHLF2424
  • AASHLF2424
  • AA61SHLF1218
  • AA35SHLF2424
  • GP166
  • GP128
  • GP168
  • DLGP618
  • AGP1618
  • GP248
  • AA35SHLF1818
  • AASHLF1818
  • AA35SHLF1218
  • GP206
  • AA61SHLF1818
  • AGP1218
  • GP208
  • AGP618
  • AASHLF1218
  • LEDA2S35
  • LEDA1S35
  • LED24V15
  • AFK1218
  • AS050
  • AFK0618

Categories

Overview

UPC 78351027807
Item Long Description Simple, heavy-duty and cost-effective with easy door removal and re-installation, this disconnect enclosure can be ordered with one to three doors to fit a range of indoor and outdoor applications
GTiN 00783510278076
Finish Powder Coated
Width 40.25 in
Size 84.12 x 40.25 x 18.12 in
Color Gray
Material Steel
Applications Arc Flash Safety; Controls and Drives; Power Distribution
Depth 460 mm
Height 84.12 in
Standard CUL Listed Per CSA C22.2 No. 94; Type 4, 12, 3R; File No. E61997,IEC 60529, IP66,NEMA/EEMAC Type 4, 12, 3R,UL 508A Listed; Type 4, 12, 3R; File No. E61997
Family Brand Name Hoffman
Sub Brand Hoffman
Type Disconnect, Free-Stand
Thickness 3.04 mm
