Hoffman APWK1711NFSS 17 x 11 Inch Brushed 304 Stainless Steel Window Kit
Product image thumbnail 0
Product image thumbnail 1
$834.26/ea
Usually ships within 6 to 8 Days
ea
Adding...
Already a Customer? Log in to view your pricing
Manufacturer Hoffman Engineering
Mfg Catalog # APWK1711NFSS
North Coast Part # 17387

Features

  • Steel Window Kits have a heavy gauge cold rolled steel formed frame (cleaned and treated for paint endurance and adhesion), painted ANSI 61 gray. The clear window is made of .25-in. (6mm) impact-resistant polycarbonate material. They are ideal for indoor and outdoor Type 3R, 4 and 12 applicatons.
  • Stainless Steel Window kits have a formed heavy gauge Type 304 stainless steel frame with a brushed finish. The clear window is made of .25-in. (6mm) impact-resistant polycarbonate material. They are ideal for indoor and outdoor Type 3R, 4X and 12 applications.
  • Non-Metallic Window kits are made of a single piece special polycarbonate blend, Makrolon, that has enhanced impact, UV, water exposure, absorption, and saturation resistance. They are ideal for indoor and outdoor Type 3R, 4, 4X and 12 applications. They are also ideal for non-metallic enclosures where exterior metallic materials are not allowed and can accommodate up to .25-in. enclosure material thickness.
  • All Window kits are easy to install and require a simple rectangular enclosure cut-out. All required hardware is furnished, along with assembly and cut- out instructions. The gasket material on all windows is resistant to oils, cutting fluids and many other liquids.
  • Window kits of the same size use the same interchangeable cut-out. Custom sizes for Steel and Stainless Steel Window Kits are available along with different finishes and gasket materials. Consult Hoffman for details.

Specifications

  • Bulletin Number: 22060
  • Model Code: 5.4
  • Ship Wt. Std. Pkg. (lbs): False
  • Interchangeable: Brushed
  • Finish: Stainless Steel
  • Catalog Number: APWK1711NFSS
  • A in.: 19.5
  • B in.: 13.5
  • C in.: 0.31
  • Window Size M x N in.: 17.00 x 11.00
  • Required Cutout Size G x H in.: 18.69 x 12.69
  • Material: Stainless Steel
  • Standards: UL 508A Component Recognized; Type 4, 4X (stainless steel and || non-metallic versions only), 3R, 12; File No. E61997. || UL 746C Component Recognized (non-metallic version only). || CSA Type 4, 4X (stainless steel and non-metallic versions only), 3R, 12; File No. 42186 || NEMA/EEMAC 4, 4X (stainless steel and non-metallic versions only), 3R, 12 || IEC 60529, IP66

Overview

UPC 78351022060
GTiN 00783510220600
Length 495 mm
Finish Stainless Steel
Width 343 mm
Size 19.50x13.50x.31 in
Color Gray
Type Window Kits
Material Steel, Stainless Steel
Applications Indoor or Outdoor Applications
Depth 27 mm
Height 19.5 in
Standard 12,13,4X (stainless Steel Version Only),CSA Type 4,File No. 42186,File No. E61997,IEC 60529,IP66,NEMA/EEMAC 4,Type 4,UL 508A Component Recognized
Family Brand Name Hoffman
Enclosure Type NEMA 4, 4X, 12, 13, IP66
Sub Brand Hoffman
