Hoffman ASG8X8X8NK Galvanized Steel NEMA 1 Screw Cover Pull Box without Knockouts

$58.38/ea

Usually ships within 6 to 8 Days

Adding...

Already a Customer? Log in to view your pricing

Features

Unique keyhole screw slots in the cover
Available with or without knockouts. Various sizes of easy-to-remove concentric knockouts on all four sides of standard boxes with knockouts.
Optional flush-mounted door frame available
Optional flush covers
Flat, removable covers fastened with plated steel screws
Provision for grounding
Mounting holes on back of box
16, 14 or 12 gauge steel or plated steel

Bulletin Number: A90P1
Material: Steel
Model Code: 49569
Ship Wt. Std. Pkg. (lbs): 13.56
Interchangeable: False
Catalog Number: ASG8X8X8NK
A in.: 8
B in.: 8
C in.: 8
Style: Galvanized
Number of Cover Screws: 4
Standards: UL 50, 50E Listed; Type 1; File No. E27525 || cUL Listed per CSA C22.2 No 40; Type 1; File No. E27525 || NEMA/EEMAC Type 1 || IEC 60529, IP30

UPC	78351049569
GTiN	00783510495695
Width	8 in
Size	8.00x8.00x8.00 in
Type	Screw-Cover, Type 1
Material	Steel
Applications	Use this enclosure in commercial and general industrial applications that require a junction or pull box. For flush installations, order flush covers and door frames separately.
Depth	8 in
Height	8 in
Standard	CUL Listed Per CSA C22.2 No 40; Type 1; File No. E27525,IEC 60529, IP30,UL 50, 50E Listed; Type 1; File No. E27525,NEMA/EEMAC Type 1
Number of Screws	4
Family Brand Name	Hoffman
Sub Brand	Hoffman
