NVENT HOF CR290226G010 230V,50/60Hz
Product image thumbnail 0
Product image thumbnail 1
Product image thumbnail 2
Usually ships within 6 to 8 Days
Already a Customer? Log in to view your pricing
Manufacturer Hoffman Engineering
Mfg Catalog # CR290226G010
North Coast Part # 1017569


  • Easy maintenance: hinged front cover allows quick access to all components; condenser coil can be cleaned while unit is still mounted to the cabinet
  • Smooth surface with minimal use of visible fasteners
  • Cleanable reusable aluminum mesh filter protects coils for maximum cooling performance
  • R134a or R407c refrigerant
  • Models for 115, 230 and 460 single phase VAC power input
  • Operating temperature range from -40 F/-40 C to 131 F/55 C (with optional low-ambient package)
  • Reliable mechanical thermostat located behind the filter of the unit
  • Robust reciprocating compressor
  • Low-carbon mild-steel sheet-metal cover for rugged factory and outdoor environments
  • High-performance fans and blowers designed for densely packed enclosures


  • Height (H) (inch): 29.5
  • Height (H) (millimetre): 749.3
  • Width (W) (inch): 15.75
  • Width (W) (millimetre): 400.05
  • Depth (D) (inch): 8.63
  • Depth (D) (millimetre): 219.202
  • Nominal Capacity Btu/h (British thermal unit per hour): 2,700
  • Nominal Capacity Watts (watt): 791
  • Nominal Voltage (volt): 230
  • Number of Phases: 1
  • Voltage AC (volt): 200-250.00
  • Operating Temperature (degree Fahrenheit): -40-131.00
  • Operating Temperature (degree Celsius): -40-55.00
  • Max Current (ampere): 3.6
  • Protection Rating: NEMA Type 12
  • Remote Access Control: No
  • Material: Stainless Steel 304
  • Finish: Brushed #3
  • Color: Unpainted
  • Thickness (T) (gauge): 18
  • Thickness (T) (millimetre): 1.21
  • Weight (pound): 98
  • Weight (kilogram): 44
  • Mechanical Advantage: Stainless steel optional
  • NEMA Rating: 12 Indoor, dust-resistant
  • Sub Brand: ProAir
  • Model: Surface Mounted
  • Voltage Rating: 230 VAC
  • BTU Rating: 2,700
  • Amperage Rating: 3.6 A
  • Power: 791 W
  • Frequency Rating: 50/60 Hz
  • Housing Material: Stainless Steel
  • Operating Temperature: 131 deg F


UPC 78351011810
Item Long Description The ProAir Harsh Environment Air Conditioner protects components exposed in corrosive environments on the ambient side of the air conditioner. The unit has few fasteners and a hinged door for quick service and maintenance access. The smooth surface and optional hood provides protection from splashed water.
GTiN 00783510118105
Width 15.75 in
Voltage 250 Volt
Type Air Conditioners
Applications Controls and Drives; Corrosive Environments; Power Distribution
Depth 219.202 mm
Height 29.5 in
Weight 98 lb
Standard CE,File No. SA6453,Refer To Tables For Specific UL/cUL Type Ratings These Air Conditioners Maintain When Properly Installed On A UL/cUL Rated Enclosure.,UL/cUL Listed
Frequency 50/60 Hz
Wattage 791 Watt
Family Brand Name Hoffman
BTU Hour 2700 BTU
Max Current 3.6 A
Max Temperature 131 degrees F
Min Temperature -40 degrees F
Sub Brand ProAir
Color Light Gray
Operating Temperature 131 deg F
Housing Material Stainless Steel
Max Power Current 791 W
Finish Brushed
Thickness 1.21 mm
