Hoffman F1010T148GV 48 Inch Straight Section
Product image thumbnail 0
Product image thumbnail 1
Product image thumbnail 2
$296.05/ea
Usually ships within 6 to 8 Days
ea
Adding...
Already a Customer? Log in to view your pricing
Manufacturer Hoffman Engineering
Mfg Catalog # F1010T148GV
North Coast Part # 668521

Features

  • Lay-in Flat-Cover Type 1 Straight Sections are used for enclosing wire and cable in wireway runs
  • Sections are completely open on one side so wires and cables can be laid in along wireway run
  • No pulling through of wires or cables prevents damage to insulation that often occurs in a pull-through wiring system
  • Flat cover design allows for mounting flush with walls or ceilings
  • Keyhole screw slots on flat covers provide easy access. Galvanized material provides superior corrosion protection for outdoor applications
  • Sections are available in lengths from 12 inch to 120 inch, with or without knockouts.

Specifications

  • Type: Straight Section
  • Height (H) (inch): 10
  • Height (H) (millimetre): 254
  • Width (W) (inch): 10
  • Width (W) (millimetre): 254
  • Depth (D) (inch): 48
  • Depth (D) (millimetre): 1,219
  • Protection Rating: NEMA Type 1
  • Material: Mild Steel
  • NEMA Rating: 1 Indoor, electrical protection
  • Modification Services: No
  • Type Number: Type 1
  • Wireway: Lay-In NEMA Type 1 Galvanized Wireway
  • Color: Unpainted
  • Finish: Galvanized
  • Thickness (T) (gauge): 14
  • Thickness (T) (millimetre): 1.9
  • Height: 10 in
  • Knockouts: No

Categories

Overview

UPC 78351043620
Item Long Description Lay-in Flat-Cover Type 1 Straight Sections are used for enclosing wire and cable in wireway runs. Sections are completely open on one side so wires and cables can be laid in along wireway run. No pulling through of wires or cables prevents damage to insulation that often occurs in a pull-through wiring system. Flat cover design allows for mounting flush with walls or ceilings. Keyhole screw slots on flat covers provide easy access. Galvanized material provides superior corrosion protection for outdoor applications. Sections are available in lengths from 12 inch to 120 inch, with or without knockouts.
GTiN 00783510436209
Width 10 in
Type Lay-in Galvanized Flat-Cover, Type 1
Material Steel
Applications Power Distribution
Depth 1,219 mm
Height 10 in
Family Brand Name Hoffman
Sub Brand Hoffman
Finish Galvanized
Thickness 1.9 mm
