Hoffman F88LE45B 8 x 8 Inch Steel 45 Degrees Inside Opening Wireway Elbow

Features

• Lay-in Hinged-Cover 45-Degree Elbows are used for continuous wireway runs with 45-degree turns
• Because sections of lay-in wireway can be mounted with covers oriented in any direction, three different 45-degree elbows are available
• Proper selection allows the user to maintain the same access and thereby preserve the lay-in feature for right-angle installations

Specifications

• Type: Elbow
• Height (H): 64 millimetre
• Width (W): 64 millimetre
• Protection Rating: NEMA Type 12
• Material: Mild Steel
• NEMA Rating: 12 Indoor, dust-resistant
• Sealing Plate Type: Flat
• Sealing Plate Quantity: 1
• Modification Services: Yes
• Type Number: Type 12
• IP Rating: IP54
• Wireway: Lay-In NEMA Type 12 Wireway
• Color: Gray
• Color Code: ANSI 61
• Finish: Galvanized
• Thickness (T): 1.9 millimetre
