NVENT HOF G520816G060 8000BTU 115V
Product image thumbnail 0
Product image thumbnail 1
Product image thumbnail 2
$6,697.41/ea
Usually ships within 6 to 8 Days
ea
Adding...
Already a Customer? Log in to view your pricing
Manufacturer Hoffman Engineering
Mfg Catalog # G520816G060
North Coast Part # 881103

Features

  • Attractive industrial design with minimal use of visible fasteners
  • Energy-efficient rotary compressor on most models
  • Cleanable, reusable aluminum mesh filter included to protect coils for maximum cooling performance in dirty environments
  • R407c and R134a refrigerants
  • 115, 230 and 400/460 VAC 3-phase power input on most models
  • Reliable mechanical thermostat on enclosure side of the unit
  • All G-series come standard with two separate thermostats for cooling and heating when a heater is equipped
  • Dust-resistant condenser coil allows the unit to be run filterless in most indoor applications
  • Dual condenser-side air movers for performance redundancy on G52 and G57 models
  • Galvanized or stainless steel cover for rugged factory and outdoor environments

Specifications

  • Height (H) (inch): 52.69
  • Height (H) (millimetre): 1,338.326
  • Width (W) (inch): 17.12
  • Width (W) (millimetre): 434.848
  • Depth (D) (inch): 11.66
  • Depth (D) (millimetre): 296.164
  • Nominal Capacity Btu/h (British thermal unit per hour): 8,000
  • Nominal Capacity Watts (watt): 2,300
  • Nominal Voltage (volt): 115
  • Voltage AC (volt): 100-120.00
  • Operating Temperature (degree Fahrenheit): 50-131.00
  • Operating Temperature (degree Celsius): 10-55.00
  • Max Current (ampere): 12.3
  • Protection Rating: NEMA Type 4
  • Remote Access Control: Yes
  • Material: Mild Steel
  • Finish: Powder Coated
  • Color: Light Gray
  • Color Code: RAL 7035
  • Thickness (T) (gauge): 20
  • Thickness (T) (millimetre): 1
  • Weight (pound): 128
  • Weight (kilogram): 58.1
  • NEMA Rating: 4 Watertight
  • Sub Brand: SpectraCool

Overview

GTiN 00783510238971
Width 17.12 in
Color Gray
Voltage 120 Volt
Type Air Conditioners
Applications Controls and Drives; Power Distribution
Depth 296.164 mm
Height 52.69 in
Weight 128 lb
Standard 3R,4,CE,IP 34 On External Loop,IP 56 Internal Loop,Telcordia GR-487 Capable (Outdoor),UL/cUL Listed Type 12
Wattage 2300 Watt
Family Brand Name Hoffman
BTU Hour 8000 BTU
Max Current 12.3 A
Max Temperature 131 degrees F
Min Temperature -40 degrees F
Sub Brand SpectraCool
Product UPC 78351023897
Finish Powder Coated
Thickness 1 mm
Material Steel
