NVENT HOF PCS5A8R Cover, Upper Rear
Product image thumbnail 0
Product image thumbnail 1
Product image thumbnail 2
$597.38/ea
Usually ships within 6 to 8 Days
ea
Adding...
Already a Customer? Log in to view your pricing
Manufacturer Hoffman Engineering
Mfg Catalog # PCS5A8R
North Coast Part # 672036

Features

  • Ground stud and mounting hardware are included
  • Optional tamper-resistant screws are available

Specifications

  • Height (H) (inch): 26.85
  • Height (H) (millimetre): 682
  • Width (W) (inch): 31.5
  • Width (W) (millimetre): 800
  • Material: Mild Steel
  • Cover Size (H x W) (millimetre): 679 x 796
  • Cover Size (H x W) (inch): 26.75 x 31.35
  • Weight (pound): 19
  • Modification Services: Yes
  • Color: Light Gray
  • Color Code: RAL 7035
  • Finish: Powder Coated
  • Thickness (T) (gauge): 16
  • Thickness (T) (millimetre): 1.52
  • Sub Brand: ProLine
  • Size: fits 682x800mm

Categories

Overview

UPC 78351036819
Item Long Description Cover fits rear opening of ProLine Sloped-Front HMI Enclosures and is secured with semi-flush cover screws along right and left cover edges. Use ProLine Frame Shelf or ProLine Grid Straps to support the operator interface. Seamless foam-in-place gasket assures watertight and dust-tight seal.
GTiN 00783510368197
Finish Powder Coated
Width 31.5 in
Size fits 682x800mm
Color Gray
Type HMI Accessories
Material Steel
Applications Controls and Drives
Height 26.85 in
Weight 19 lb
Family Brand Name Hoffman
Sub Brand ProLine
Thickness 1.52 mm
