Hoffman PDS78R 31.18 x 25.16 Inch 14 Gauge Steel Solid Industrial Cabinet Door
Product image thumbnail 0
Product image thumbnail 1
Product image thumbnail 2
$504.39/ea
Usually ships within 6 to 8 Days
ea
Adding...
Already a Customer? Log in to view your pricing
Manufacturer Hoffman Engineering
Mfg Catalog # PDS78R
North Coast Part # 213329

Features

  • EMC doors are finished with paint over plated surfaces
  • Optional data pockets, door stops, grounding kits and 180-degree hinges are available
  • Hinges have easy slide retained hinge pins
  • Door gasket is foam-in-place urethane to provide a resilient, seamless seal
  • Two grounding studs are furnished. All mounting hardware is included

Specifications

  • Material: Mild Steel
  • Dimensions (H x W) (millimetre): 639 x 792
  • Dimensions (H x W) (inch): 25.16 x 31.18
  • Fits Frame (A x B): 700 x 800
  • Door Type: Steel
  • Modification Services: Yes
  • Color: Light Gray
  • Color Code: RAL 7035
  • Finish: Powder Coated
  • Thickness (T) (gauge): 14
  • Thickness (T) (millimetre): 1.9
  • Sub Brand: ProLine
  • Size: fits 700x800mm

Related Products

Accessory

  • LEDPUCK

Overview

UPC 78351094850
Item Long Description Solid Doors include a removable door bar system on doors taller than 700 mm and wider than 400 mm. Hinge side is reversible. A flush bezel latch operates the 3-point latching system. Doors for 700-mm frames have 2-point latching. Hidden hinges (130-degree swing) permit attachment to the front or back of each enclosure frame. The use of a side-door adapter or a cable entry cabinet allows doors to be attached to the sides of the enclosure frame.
GTiN 00783510948504
Finish Powder Coated
Width 31.5 in
Size fits 700x800mm
Color Gray
Type Doors and Door Accessories
Material Steel
Applications Controls and Drives; Power Distribution
Height 27.56 in
Family Brand Name Hoffman
Gauge 14 AWG
Sub Brand ProLine
Thickness 1.9 mm
