Hoffman PF22125 2200 x 1200 x 500 mm Enclosure Frame
Product image thumbnail 0
Product image thumbnail 1
Product image thumbnail 2
$1,239.13/ea
Usually ships within 6 to 8 Days
ea
Adding...
Already a Customer? Log in to view your pricing
Manufacturer Hoffman Engineering
Mfg Catalog # PF22125
North Coast Part # 342019

Features

  • 12 gauge (2.5mm), roll-formed steel frame with welded steel corners
  • Open roll-formed profile design affords complete surface corrosion protection and assembly access
  • RAL 7035 textured light-gray polyester powder paint finish
  • Frame features a 25-mm DIN standard, alternating rectangular and round hole pattern
  • Flange trough collar on door and side openings deflect dust and debris away from the enclosure interior
  • Welded rear centerpost and cross members to facilitate population in either enclosure bay; no front center post allowing full access for subpanel mounting
  • Integral frame channels support the full weight of the mounting subpanel (sold separately)
  • Individual frames designed for joining/baying in multiple directions with the inclusion of joining kits
  • Provisions for mounting subpanel, rack mounting and grid/rail system mounting to support many unique customer applications; optional center upright to accomplish mounting in individual bays sold separately
  • Appropriate gasketed door(s) and covers are required to maintain a Type-12 environmental rating, sold separately

Specifications

  • Material: Mild Steel
  • Max Subpanel Size (millimetre): 2085 x 1130
  • Max Subpanel Size (inch): 82.09 x 44.49
  • Max Rack Mounting Space: 47U x 2
  • Nominal Frame Size (A x B x C) (millimetre): 2200 x 1200 x 500
  • Modification Services: Yes
  • Type Number: Type 12
  • IP Rating: IP55
  • Color: Light Gray
  • Color Code: RAL 7035
  • Finish: Powder Coated
  • Thickness (T) (gauge): 12
  • Thickness (T) (millimetre): 2.66
  • Sub Brand: ProLine
  • Size: 2000x1200x500mm

Overview

UPC 78351096080
Item Long Description The ProLine frame is the foundational design element that protects the components inside this modular enclosure. The frame was designed to maintain a solid square structure - a solid foundation for the electrical enclosure.
GTiN 00783510960803
Finish Powder Coated
Width 47.24 in
Size 2000x1200x500mm
Color Gray
Type Frames
Material Steel
Applications Controls and Drives; Power Distribution
Depth 19.69 in
Height 86.61 in
Family Brand Name Hoffman
Rack Unit 47
Sub Brand ProLine
Thickness 2.66 mm
