NVENT PLCSKIT P and P Leak Comp Ser
$180.68/ea
Usually ships within 6 to 8 Days
ea
Adding...
Already a Customer? Log in to view your pricing
Manufacturer Hoffman Engineering
Mfg Catalog # PLCSKIT
North Coast Part # 1891469

Features

  • All exterior components are 316 stainless steel or corrosion-resistant composite
  • Space-saving flush or exterior mounted models available
  • Local visual indicators provide system status
  • Leak compensation models are equipped with rapid purge valve and visual purge status indicator
  • All models utilize dry, clean inert gas supply of 60 PSI (4 bar) to 115 PSI (8 bar)
  • Ambient operating temperature -4F (-20C) to 131F (55C)
  • Type X models provide automatic purge cycle and 4PNO/20A/440VAC power contactor with 115 VAC or 230 VAC coil

Notes

  • For all IEC and ATEC applications, the final or complete integrated assembly must be submitted to a notified body for certification.
  • See Specification Sheet for Purge and Pressurization Systems and Certifications table.

Accessories

  • Service Parts Kit for both Leak Compensation and Continuous Flow models

Specifications

  • Bulletin Number: HLP
  • Model Code: 27148
  • Ship Wt. Std. Pkg. (lbs): 0.0
  • Interchangeable: False
  • Catalog Number: PLCSKIT
  • Description: Purge and Pressurization Leakage Compensation Service Kit
  • Standards: Ex [px] Ex [p] || IECEx SIR.0019X [Gb, Db] || Europe, ATEX Category 2 GD || Cert no Sira 14ATEX1045X || USA/Canada NFPA496 Cl I Div 1 Groups A, B, C & D || UL E466718 || Ex [py] Ex [p] || IECEx SIR.0019X [Gb, Db] || Europe, ATEX Category 2 GD || Cert no Sira 14ATEX1045X || North America Cl I Div 1 Groups A, B, C & D || For protecting Cl I Div 2 equipment || UL E466718 || Ex [pz] Ex [p] || IECEx SIR.0019X [Gc, Dc] || Europe, ATEX Category 3 GD || Cert no Sira 14ATEX1045X || North America Cl I Div 2 Groups A, B, C & D || UL E466718

Categories

Overview

UPC 78351027148
GTiN 00783510271480
Type Purging and Pressurization Systems
Applications Hazardous Environments
Family Brand Name nVent HOFFMAN
Sub Brand Hoffman
