Hoffman PP1686 PROLINE 16 x 8 x 6 Inch Enclosure
Product image thumbnail 0
Product image thumbnail 1
Product image thumbnail 2
$2,070.45/ea
Usually ships within 6 to 8 Days
ea
Adding...
Already a Customer? Log in to view your pricing
Manufacturer Hoffman Engineering
Mfg Catalog # PP1686
North Coast Part # 935196

Features

  • Frames are roll-formed, robotically welded with solid steel, fully welded corners; accommodates 25 mm DIN standard
  • Standard door bars increase strength and rigidity and allow for an extra mounting options
  • Seamless foam-in-place gasket provides a protective seal against moisture and contaminants
  • Gasket and latching system together ensure a solid seal with low closure force
  • Reversible door, left hinged as a default, with 130-degree swing
  • Galvanized mounting plates
  • Capped ground studs on door, rear and top panel
  • Integral frame channels support the full weight of the mounting plates
  • Frame thickness 12 gauge/2.5 mm carbon steel powder painted in RAL 7035
  • Door thickness 14 gauge/2.0 mm, carbon steel powder painted – for details please check reference tables

Specifications

  • Height (H) (inch): 62.99
  • Height (H) (millimetre): 1,600
  • Width (W) (inch): 31.5
  • Width (W) (millimetre): 800
  • Depth (D) (inch): 23.62
  • Depth (D) (millimetre): 600
  • Protection Rating: NEMA Type 12
  • Material: Mild Steel
  • NEMA Rating: 12 Indoor, dust-resistant
  • Type: Single Door
  • Modification Services: Yes
  • Color: Light Gray
  • Color Code: RAL 7035
  • Finish: Powder Coated
  • Sub Brand: ProLine
  • Size: 1600x800x600mm

Related Products

Accessory

  • LED24V15
  • PT68
  • PLTDDC168
  • PMB86
  • PPT86
  • PVT3F862
  • PPB186
  • PDS168
  • PPTHP2
  • PPT1
  • PBB166
  • ADP2
  • PCE16650
  • PPTHP1
  • PAC416T86
  • PPTHP1C
  • PAC226T86
  • PSS166
  • PAC426T86
  • PB186
  • PPB286
  • PPT1C
  • PT68SS
  • PTB186
  • PB086
  • PPTHP86
  • PVT3F861
  • PPT2
  • PCS168
  • PDWG168
  • PB086SS
  • PSS166SS
  • PTDDC168
  • PGP86
  • PGPV86
  • PGS2K
  • ADP1
  • PFHKBL
  • PGS4K
  • PLEM12
  • PLFSWD
  • P1032CN
  • AS1032
  • PJ2F
  • PGK
  • PGS6K
  • PC1M12
  • PGH3S6
  • PGFM6
  • PCEGP
  • P19RP3UP
  • PJB2F
  • PSHDM
  • P19RP1UP
  • P19RP4UP
  • PFHDF
  • P19RP5UP
  • P19RP2UP
  • PLHK
  • PMLSK
  • PDSK
  • P19RP6UP
  • PGH1S6
  • PMLMAK
  • PLM12
  • PEK115NDH
  • PJ2FF
  • PGFGM6
  • PRB100
  • P19RP1UA
  • ES1224
  • PM5CN
  • PFHPBL
  • PGH3S9
  • PFBK
  • PFHDBL
  • PJ2FB
  • P19DR2US
  • P19RP5UA
  • ASM5T
  • PJLBSS
  • P19SH6
  • ASM5
  • A19FT3B
  • P19RP3UA
  • PRA1916TH
  • P19RP7UP
  • PRA1916TP
  • P19RP8UP
  • A19FT6B
  • PG6
  • PKOSLFH
  • P19RP16UP
  • PFHPK
  • P19RP6UA
  • PGH1S8D
  • PH180
  • PPP48G
  • P19RP4UA
  • P19RP2UA
  • PDSRKL
  • P19RP10UP
  • PVT3F1
  • P19RP9UP
  • PKODBK3
  • A19KBC2B
  • PFFM12
  • P19RP12UP
  • P19RP7UA
  • PBRAA
  • P19SH5
  • PFBS
  • PPBCV1800
  • PPP88
  • PPP108
  • PFSH86
  • PGH1S9
  • PRB50
  • P19RP8UA
  • PEK460NDH
  • P19DR1US
  • P24RP6UP
  • PPF168
  • PPP98G
  • P19WS
  • PKODBK3FH
  • PMLEK
  • P19RP9UA
  • PFB19
  • PKOSM7
  • PPBCV2800
  • P19RP11UA
  • PDKL
  • PSHLOCK
  • A16SL2U
  • P19RP11UP
  • PJ2FD
  • PPP48
  • PSF170K
  • P19RP16UA
  • PBARA6
  • PTR8
  • ATRSDVR
  • P19RP12UA
  • PFK6020
  • PEK230NDH
  • PFSHP86
  • PPP98
  • PSAK120
  • PWMR6
  • P19DR3US
  • PRB200
  • P19RP10UA
  • P24RP4UA
  • PLEGSS
  • P24RP5UP
  • P24RP8UP
  • PFBSSS
  • PKOSM8
  • PSF8
  • PJLBFB
  • PKOTM7FH
  • PGH3S16V
  • PKOTM8FH
  • PPP88G
  • PSF148
  • P24RP2UP
  • PFB24
  • P23RP4UP
  • PFP19RA
  • PKOSM7FH
  • PKOTM7
  • PKOTM8
  • PMLFB
  • PSFG
  • PPBSK
  • PPF168G
  • PPP108G
  • P23RP2UP
  • PKODBK3SS
  • PTJT
  • P23RP3UP
  • P24RP4UP
  • P24RP8UA
  • PMBLM12
  • PSF78
  • P23RP1UP
  • P23RP3UA
  • P23SH6
  • P24SH5
  • P24SH6
  • PCU16
  • PDKLRKPR
  • PFPK168LR
  • PKOTM65
  • PPSH86
  • PRA237TP
  • PSF168
  • PVT3F2
  • P23RP1UA
  • P23RP4UA
  • P23SH5
  • P24RP2UA
  • P24RP3UP
  • P24RP5UA
  • PFPK168C
  • PJP16
  • PJP16G
  • PPFSM166
  • PPFSM166G
  • PRA2314TP
  • PRA2316TP
  • PRA2416TH
  • PRA2416TP
  • PRAM16
  • PSAK170
  • PSP168

Overview

UPC 78351014177
Item Long Description ProLine Industrial Packages are full-featured, ready-to-use enclosure solutions that make it unnecessary to order each component separately. For convenience, a single part number includes a frame, solid door(s), handle and key lock, a solid top, a solid rear cover, a full mounting subpanel, a gland plate, and four lifting eyes. Side covers are ordered separately to accommodate joining/baying applications.
GTiN 00783510141776
Finish Polyester Powder Painted
Width 31-1/2 in
Size 1600x800x600mm
Color 7035 Light Gray
Type Industrial Packages, Single Door
Material Steel
Applications For Industrial Controls (Drives, PLC, DCS, SCADA, VFD), Networking in Industrial Environments, Electrical Panels, Equipment Protection, Power Distribution, HMI Controls, EMI/EMC (Electromagnetic Interference/Compatibility) Applications
Depth 23.62 in
Height 62.99 in
Standard CSA File Number 42186: Type 12,File Number E61997,IEC 60529,IP55,NEMA/EEMAC Type 12,Type 12,UL 508A Listed,VDE IP55
Family Brand Name Hoffman
Sub Brand ProLine
Mounting Type Floor
Gauge 12
Cover Type Reversible Hinged, Gasketed
