AIR COND T43-0816-G150
$6,833.74/ea
Usually ships within 6 to 8 Days
ea
Adding...
Already a Customer? Log in to view your pricing
Manufacturer Hoffman Engineering
Mfg Catalog # T430816G150
North Coast Part # 1010250

Features

  • Stock models equipped with head pressure control for low-ambient operation, compressor heater, coated condenser coil, malfunction switch, thermostat and heater package
  • R134A or R-407C earth-friendly refrigerant
  • Models for 115, 230 and 460 VAC power input
  • UL Listed to save customers time and money with agency approvals (some models UL recognized)
  • Outdoor model operating temperature range from -40 F/-40 C to 131 F/55 C
  • Exterior and fully recessed mounting options on many models
  • Compact footprint to minimize real estate and maximize capacity
  • Reliable mechanical thermostat on enclosure side of the unit
  • Dual condenser-side air movers for performance redundancy
  • Painted galvanized sheet-metal cover for rugged factory and outdoor environments
  • Easy-mount flanges for simple installation
  • Cleanable, reusable aluminum mesh filter protects coils for maximum cooling performance
  • Mounting hardware, gaskets and user manual furnished with the unit
  • Every unit functionally tested before shipping
  • Standard Outdoor Air Conditioner models also include:
  • Telcordia GR-487 capable
  • Thermostat
  • Corrosion-resistant components
  • Malfunction switch
  • Compressor heater
  • Head pressure control
  • Enclosure heater

Notes

  • ProAir Harsh Environment air conditioner may be more appropriate. Refer to ProAir Harsh Environment air conditioner catalog section. Consult the Factory for availability and catalog number.
  • Reference the Spec Sheet in the Downloads tab for complete product specifications, performance curves and detailed drawings.

Specifications

  • Model Code: 23328
  • Bulletin Number: MCL
  • Catalog Number: T430816G150
  • Description: Outdoor Model with Heat Pkg.
  • Width (in.): 15.75
  • Depth (in.): 10.90
  • Fahrenheit Min.: -40
  • Fahrenheit Max.: 131
  • Max Current (A): 11.2
  • Weight (lb.): 125
  • Voltage: 100 - 120 VAC
  • Nominal BTU/Hr.: 8600
  • Nominal Watts: 2500
  • Height (in.): 43.0
  • Standards: UL/cUL Listed; Type 12, 3R, 4; 4X optional; File No. SA6453 || UR/cUR Recognized || UR/cUR Recognized on select models, reference performance data tables. || CE || EAC || Telcordia GR-487 capable

Overview

UPC 78351023328
GTiN 00783510233280
Width 15.75 in
Color Gray
Voltage 120 Volt
Applications Industrial
Depth 10.90 in
Height 43.0 in
Weight 125 lb
Wattage 2500 Watt
Family Brand Name Hoffman
BTU Hour 8600 BTU
Max Current 11.2 A
Max Temperature 131 degrees F
Min Temperature -40 degrees F
Sub Brand T-Series
