NVENT HOF WCHE04926002 230V AIR TO
$2,090.99/ea
Usually ships within 6 to 8 Days
ea
Adding...
Already a Customer? Log in to view your pricing
Manufacturer Hoffman Engineering
Mfg Catalog # WCHE04926002
North Coast Part # 1016815

Features

  • Filterless design
  • NEMA power cord connection standard
  • Copper pipe and aluminum fins heat exchanger core
  • Air movers with thermal protection
  • Regulating mechanical thermostat set at 35 C (95 F), differential of 4 C (7 F)
  • Inside cabinet temperature from 10-50 C (50-122 F)
  • Solenoid water valve
  • UL Listed to save customers time and money with agency approvals
  • Recovery of condensation system and condensation discharge pipe
  • Requires an available cooled water source

Notes

  • Reference the Spec Sheet in the Downloads tab for complete product specifications.

Specifications

  • Model Code: 25614
  • Bulletin Number: MCLHE
  • Catalog Number: WCHE04926002
  • Description: WCHE04-2200
  • Width (in.): 15.75
  • Depth (in.): 8.07
  • Fahrenheit Min.: 50
  • Fahrenheit Max.: 122
  • Max Current (A): 0.8
  • Weight (lb.): 44.10
  • BTU/Hr. @ Δt 25 C: 7506
  • Watts @ Δt 25 C: 2200
  • Voltage: 200 - 250 VAC
  • Height (in.): 36.41
  • Standards: UL/cUL Listed; Type 12; File No. SA33866 || CE || EAC (230V models only) || IP55/IP54 (reference item technical data)

Overview

UPC 78351025614
GTiN 00783510256142
Finish Polyester Powder Coated
Width 15.75 in
Color RAL 7035 Light Gray
Voltage 250 Volt
Applications For Industrial Process Controls, Industrial Robotics Controls, Electronic Cabinets in Harsh Environments, Conveyor Systems
Depth 8.07 in
Height 36.41 in
Weight 44.10 lb
Standard CE,EAC (230V Models Only),IP55/IP54 (reference Item Technical Data),UL/cUL Listed; Type 12; File No. SA33866
Wattage 2200 Watt at 25 C
Temperature Rating 50 - 122 F
Family Brand Name Hoffman
Housing Material Mild Steel
Control Type Mechanical Thermostat
TC Connection Power Cord
Max Current 0.8 A
Max Temperature 122 degrees F
Min Temperature 50 degrees F
Blade Dimensions 15-3/4 in W x 8.07 in D x 36.41 in H
Sub Brand ClimaGuard
Type Heat Exchangers
