Hoffman WS242408SS 24 x 24 x 8 Inch 14 Gauge 304 Stainless Steel NEMA 4X Wall Mount Enclosure
Product image thumbnail 0
Product image thumbnail 1
$2,449.87/ea
Usually ships within 12 to 18 Days
ea
Adding...
Already a Customer? Log in to view your pricing
Manufacturer Hoffman Engineering
Mfg Catalog # WS242408SS
North Coast Part # 72146

Features

  • Seams continuously welded and ground smooth
  • Smooth Type 304 stainless steel lift-off bullet-style hinges
  • Hinges are shielded by door
  • Hinged side of door has provisions to allow direct flushing of hinge area
  • 20-degree sloped top facilitates runoff of water and cleaning solutions and prohibits the placement of objects on the top of the enclosure
  • 170-degree door opening
  • Door edges are sloped 20-degrees at top and bottom edges to facilitate runoff
  • Slanted flange trough collar prohibits pooling of fluids along the top edge of the enclosure opening
  • Stainless steel quarter-turn latches furnished with flush slotted insert
  • Seamless foam-in-place gasket

Specifications

  • Height (H): 610 millimetre
  • Width (W): 610 millimetre
  • Depth (D): 203 millimetre
  • Protection Rating: NEMA Type 12
  • Material: Stainless Steel 304
  • NEMA Rating: 4X Watertight, corrosion-resistant
  • Panel: A24P24
  • Conductive Panel: A24P24G
  • Stainless Steel Panel: A24P24SS6
  • Latch Quantity: 4
  • Modification Services: Yes
  • Type Number: Type 3R
  • IP Rating: IP66
  • Color: Unpainted
  • Finish: Brushed #4
  • Thickness (T): 2 millimetre

Related Products

Accessory

  • LED24V15
  • AS050SS
  • T150116G152
  • A24P24
  • A24P24G
  • A24P24SS6
  • CMFKSS
  • WSSOK2SS
  • WSSOK6SS
  • WSSOK4SS
  • WSSOK1SS
  • WSLPL
  • WSHPL
  • AVDR4SS4
  • H2OMITTER
  • ABS6
  • ABS12

Overview

UPC 78351013092
GTiN 00783510130923
Width 610 mm
Size 24.00x24.00x8.00 in
Type Single Door, Double Lock
Material Stainless Steel
Applications Controls and Drives; Corrosive Environments; Hygienic Environments
Mounting Type Wall
Depth 203 mm
Height 610 mm
Standard CUL Listed Per CSA C22.2 No 94; Type 4, 4X, 12; File Number E61997,IEC 60529, IP66,NEMA/EEMAC Type 4, 4X, 12,NSF 169,UL 508A Listed; Type 4, 4X, 12; File Number E61997
Family Brand Name Hoffman
Sub Brand Watershed
Finish Brushed
Thickness 2 Millimetre mm
