Hubbell Wiring Devices 07401108 1-1/4 Inch Male Threaded 1 to 1.125 Inch Straight Deluxe Cord Grip with Mesh
Product image thumbnail 0
Product image thumbnail 1
$180.40/ea
Usually ships within 6 to 8 Days
ea
Adding...
Already a Customer? Log in to view your pricing
Manufacturer Hubbell / Kellems
Mfg Catalog # 07401108
North Coast Part # 664319

Features

  • Stainless steel mesh is corrosion resistant
  • Multiweave grip gives cable arc-of-bend control
  • Endless weave provides easy cable/flexible conduit installation
  • Standard Product

Performance

  • Environmental - Flammability - UL 94HB (Strand grip), UL 94V-2(Fitting)
  • Environmental - Wet Locations - Suitable for use in wet locations when used with a listed sealing ring between box and fitting
  • Environmental - Hazardous Locations - Suitable for use in hazardous locations per Class I Div. 2, Class II Div. 1 & 2, Class III Div. 1 & 2 N.E.C
  • Environmental - Operating Temperatures - –30°F to +240°F (–34°C to +115°C)

Industry Standard(s)

  • UL Listed

Specifications

  • Application: 90 Degree Male- Form 5
  • Cable Diameter Range: 1.000 in-1.125 in
  • Cable Size: 1.000"-1.125" (2.54-2.86)
  • Carton Quantity: 5 EA
  • Conductor Range: 1-1.125 in (2.54-2.86 mm)
  • Display Size: 1 1/4" NPT
  • Environmental Conditions: Suitable For Use In Wet Locations When Used With A Listed Sealing Ring Between Box And Fitting.
  • Item Type: Deluxe Cord Grips
  • Material: Aluminum Fittings, Stainless Steel Mesh
  • Material - Mounting Hardware: Locknut or Tapped Opening
  • Minimum Order Quantity: 1 EA
  • Number Of Conductors: Single
  • OEM Brand Name: Hubbell Wiring Device-Kellems
  • SAP Material Group 5: A30
  • Series: Deluxe Cord Grips
  • Style: For Insulated Cables
  • Temperature Rating: Minimum -30 Deg F to 240 Deg F (-34 Deg C to 115 Deg C)
  • Thread Size: 1 1/4" NPT
  • Type: 90 Degree Male Thread
  • EU RoHS Indicator: Yes
  • Each - Length: 14.000 in
  • Each - Height: 2.300 in
  • Each - Width: 4.300 in
  • Special Features: Standard Product
  • Standard: UL Listed

Overview

UPC 78358516733
GTiN 00783585167336
Length 14.000 in
Width 4.300 in
Size 1 1/4" NPT
Type Standard, Deluxe, 90
Material Aluminum Fitting, Stainless Steel Mesh
Number of Conductors 1
Product Series Deluxe Cord Grips
Applications For 90 Male - Form 5
Height 2.300 in
Temperature Rating -30 to 225 F
Family Brand Name Hubbell Wiring Device Kellems
Carton Qty 5
Sub Brand Kellems Wire Management
Cable Type Jacketed UL Listed Cable
Cable Size 1 - 1.1 in
TC Connection 1-1/4 in MNPT
