HCI GFTWRST20SNAPW 20A COM SELF TES
Product image thumbnail 0
Product image thumbnail 1
Product image thumbnail 2
$48.20/ea
ea
Adding...
Already a Customer? Log in to view your pricing
Manufacturer Hubbell / Kellems
Mfg Catalog # GFTWRST20SNAPW
North Coast Part # 1162075

Features

  • Audible SNAP, indicates solid connection
  • Patented shutter design for tamper-resistant protection
  • Meets NEC requirements for TR (517-18c) and WR (406.9), UV and corrosion resistance for harsh and damp applications
  • Patented AUTOGUARD® self test technology
  • Protects against line and load reversal, no power to the face or downstream if device is miswired
  • SNAP Connect, Self Grounding, Weather and Tamper Resistant, AUTOGUARD Self test Technology

Specifications

  • Country of Origin: CN
  • Current / Amperage Rating: 20 A
  • Dimensions: 3.28 in x 1.77 in x 1.47 in
  • Each - Height: 7.044 in
  • Each - Length: 5.048 in
  • Each - Width: 2.048 in
  • Height: 1.47 in
  • Horsepower - Maximum: 1
  • Industry Standard(s): Meets All NEC® Requirements
  • Length: 3.28 in
  • Show Add To ProjectList: Yes
  • Amperage Rating: 20 A
  • Application: Commercial Grade
  • Color: White
  • Environmental Conditions: Weather Resistant
  • NEMA Rating: 5-20R
  • Phase: Single Phase
  • Size: 3.28 in x 1.77 in x 1.47 in
  • Special Features: SNAP Connect, Self Grounding, Weather and Tamper Resistant, AUTOGUARD Self test Technology
  • Standard: Meets All NEC® Requirements
  • Type: Tamper-Resistant, Weather Resistant
  • Voltage Rating: 125 V
  • Wattage: 1875 W
  • Wire Size: #12 AWG
  • Voltage Rating Description: 125 V
  • Width: 1.77 in

Certifications

  • EU RoHS Indicator: Contact Manufacturer

Overview

UPC 88377886018
Item Long Description Straght Blade Devices, SNAP-Connect, Weather and Tamper-Resistant, AUTOGUARD, Self Test, GFCI Receptacle, 20A 125V, 2-Pole 3-Wire Grounding, 5-20R, White.
GTiN 00883778860188
Length 3.28 in
Width 1.77 in
Size 3.28 in x 1.77 in x 1.47 in
Color White
Voltage 125 Volt
Type Decorator, Self-Test, Tamper-Resistant
Material Thermoplastic
Conductor Size 14-12 AWG
Product Series Heavy Duty
Applications Commercial Grade
Mounting Type Screw
Height 1.47 in
Grade Commercial
Wire Size 12 AWG
Wattage 2500 Watt
Family Brand Name Hubbell Wiring Device Kellems
TC Connection Connectorized
Current 20 A
Environmental Conditions Weather-Resistant
Number of Poles 2 Pole
Number of Wires 3
Sub Brand SnapConnect
Standard NEC
