HCI HBL3200RS2WR PS, INS, RECP, 2P3
Product image thumbnail 0
Product image thumbnail 1
Product image thumbnail 2
$1,725.14/ea
Usually ships within 6 to 8 Days
ea
Adding...
Already a Customer? Log in to view your pricing
Manufacturer Hubbell / Kellems
Mfg Catalog # HBL3200RS2WR
North Coast Part # 290

Features

  • Watertight neoprene sealing glands for reliable seal
  • Spring-Loaded, gasketed cover for dust-tight seal
  • Pin chamber confines arcing within the interior chamber
  • Watertight

Specifications

  • Country of Origin: US
  • Current / Amperage Rating: 200 A
  • Each - Height: 8.100 in
  • Each - Length: 13.100 in
  • Each - Width: 9.500 in
  • Industry Standard(s): CSA Certified to CSA Spec. C22.2 No. 182.1;UL Listed and CSA Certified Type 4X;UL Standard 1682
  • Performance: Electrical - Current Interrupting - Certified for current interrupting at full rated current;Electrical - Dielectric Voltage - Withstands 3,000V AC;Electrical - Max. Working Voltage - 600V AC RMS;Environmental - Flammability (Enclosure) - UL 94V-0 and CSA C22.2 No. 0.17;Environmental - Moisture Resistance - Type 3, 4, 4X per UL 50E and CSA 22.2, No. 94;Environmental - Operating Temperatures - Max. Continuous 75°C;Min. -40°C w/o impact -25° with impact;Mechanical - Impact Resistance - Per CSA C22.2, No. 182.1, UL 1682;Mechanical - Product Identification - Identification and ratings are permanently fastened to the device housing;Mechanical - Terminal Identification - Terminals identified in accordance with UL 1686(1, 2, 3, Green)
  • Amperage Rating: 200 A
  • Application: Metallic with Nylon Shroud
  • Environmental Conditions: Watertight
  • NEMA Rating: Non-NEMA
  • Number of Poles: 2-Pole
  • Number of Wires: 3-Wire
  • Phase: Single Phase
  • Special Features: Watertight
  • Standard: CSA Certified to CSA Spec. C22.2 No. 182.1; UL Listed and CSA Certified Type 4X; UL Standard 1682
  • Type: Watertight Receptacle
  • Voltage Rating: 600 VAC/250 VDC
  • Wattage: 120000
  • Wire Size: #2 AWG to #4/0 AWG
  • Voltage Rating Description: 600V AC/250V DC

Certifications

  • EU RoHS Indicator: Yes

Overview

GTiN 00783585012087
Length 13.1 Inch
Width 9.500 in
Size Standard Sized Product
Color Black/Gray
Voltage 600 Volt
Type Single Flanged-Reversed
Material Thermoplastic
Conductor Size 4/0-2 AWG
Product Series UL 1686 Class 1 Insulgrip
Applications High Ampacity Connections
Mounting Type Screw
Height 8.1 Inch
Wire Size 2-0000 AWG
Wattage 120000 Watt
Family Brand Name Hubbell Wiring Device Kellems
Grounding Style 2
TC Connection Pressure Screw Terminals
Current 200 A
Environmental Conditions Watertight
Number of Poles 2 Pole
Number of Wires 3
Sub Brand Pin and Sleeve Devices
Product UPC 78358501208
Standard CSA,CSA Spec. C22.2 No. 182.1,Type 4X,UL,UL Standard 1682
Country of Origin USA
