Hubbell Wiring Devices HBL5652I 15 Amp 250 Volt 2-Pole 3-Wire NEMA 6-15R Ivory Straight Blade Duplex Receptacle
Product image thumbnail 0
Product image thumbnail 1
Product image thumbnail 2
$21.87/ea
Usually ships within 6 to 8 Days
ea
Adding...
Already a Customer? Log in to view your pricing
Manufacturer Hubbell / Kellems
Mfg Catalog # HBL5652I
North Coast Part # 495117

Features

  • One-piece brass integral ground strap
  • Unique bypass contact design
  • Self Grounding

Specifications

  • Country of Origin: US
  • Current / Amperage Rating: 15 A
  • Each - Height: 1.540 in
  • Each - Length: 4.160 in
  • Each - Width: 1.790 in
  • Horsepower - Maximum: 1.5
  • Industry Standard(s): Certified to CSA 22.2, No. 42 File 285;Guide RTRT Fed Spec WC596G;NEMA® WD-6 Compliant;UL Listed to UL498 File No. E2186
  • Length: 3.28 in
  • Performance: Electrical - Current Interrupting - Certified for current interrupting at full rated current;Electrical - Dielectric Voltage - Withstands 2,000V minimum;Environmental - Flammability - UL 94 V-2 or better;Environmental - Operating Temperatures - Maximum continuous 75°C minimum -40°C (w/o impact);Mechanical - Product Identification - Ratings are a permanent part of the device;Mechanical - Terminal Accommodation - #14-#10 AWG copper stranded or solid conductor only;Mechanical - Terminal Identification - Terminals identified in accordance with UL 498 and CSA
  • Show Add To ProjectList: Yes
  • Amperage Rating: 15 A
  • Application: Extra Heavy Duty
  • Color: Ivory
  • Dielectric Strength: Withstands 2,000V minimum
  • Environmental Conditions: Indoor Dry Unless Protected By Additional Means
  • NEMA Rating: 6-15R
  • Number of Poles: 2-Pole
  • Number of Wires: 3-Wire
  • Phase: Single Phase
  • Special Features: Self Grounding
  • Standard: Certified to CSA 22.2, No. 42 File 285; Guide RTRT Fed Spec WC596G; NEMA® WD-6 Compliant; UL Listed to UL498 File No. E2186
  • Voltage Rating: 250 V
  • Wattage: 3750 W
  • Wire Size: #14 AWG to #10 AWG
  • Voltage Rating Description: 250 V
  • Width: 1.33 in

Certifications

  • EU RoHS Indicator: Yes

Overview

UPC 78358543538
Item Long Description Straight Blade Devices, Receptacles, Duplex, Specification Grade, 2-Pole 3-Wire Grounding, 15A 250V, 6-15R, Ivory, Single Pack
GTiN 00783585435381
Length 3.28 in
Width 1.33 in
Size Standard Sized Product
Color Ivory
Voltage 250 Volt
Type Traditional Duplex
Material Nylon
Applications Extra Heavy Duty
Height 1.540 in
Weight 0.2 lb
Wire Size 14-10 AWG
Wattage 3750 Watt
Family Brand Name Hubbell Wiring Device Kellems
TC Connection Side Wired Only
Current 15 A
Number of Poles 2 Pole
Number of Wires 3
Sub Brand Straight Blade Devices
Standard CSA 22.2,Guide RTRT Fed Spec WC596G,NEMA WD-6,No. 42 File 285,UL,UL498 File No. E2186
Dielectric Strength Withstands 2,000V minimum
Environmental Conditions Indoor Dry Unless Protected By Additional Means
