Hubbell Wiring Devices HBL9432C 30 Amp 125/250 Volt 3-Pole 4-Wire NEMA 14-30P Black Nylon Straight Blade Plug
Product image thumbnail 0
Product image thumbnail 1
Product image thumbnail 2
$103.32/ea
Usually ships within 6 to 8 Days
ea
Adding...
Already a Customer? Log in to view your pricing
Manufacturer Hubbell / Kellems
Mfg Catalog # HBL9432C
North Coast Part # 209726

Features

  • Catalog number, ratings and certifications molded in face
  • Gripping ribs provide secure gripping area
  • Supertough nylon housing

Specifications

  • Country of Origin: US
  • Current / Amperage Rating: 30 A
  • Dimensions: 4.5 in x 3.38 in x 2.37 in
  • Each - Height: 3.418 in
  • Each - Length: 5.168 in
  • Each - Width: 3.168 in
  • Height: 2.37 in
  • Horsepower - Maximum: 2
  • Industry Standard(s): Certified to CSA;UL Listed File E1706
  • Length: 4.5 in
  • Performance: Electrical - Current Interrupting - Certified for current interrupting at full rated current;Electrical - Dielectric Voltage - Withstands 2,000V minimum;Environmental - Flammability - UL 94 HB;Environmental - IP Suitability - IP20;Environmental - Operating Temperatures - Maximum continuous 75°C, minimum -40°C (w/o impact);Mechanical - Product Identification - Ratings are a permanent part of the device;Mechanical - Terminal Accommodation - #12 AWG through #4 AWG copper wire only;Mechanical - Terminal Identification - Terminals identified in accordance with UL 498 and CSA
  • Show Add To ProjectList: Yes
  • Amperage Rating: 30 A
  • Color: Black
  • NEMA Rating: 14-30P
  • Number of Poles: 3-Pole
  • Number of Wires: 4-Wire
  • Size: 4.5 in x 3.38 in x 2.37 in
  • Standard: Certified to CSA; UL Listed File E1706
  • Type: Plug
  • Voltage Rating: 125; 250 (unece.unit.VLT; unece.unit.VLT)
  • Wattage: 7500 W
  • Wire Size: #12 AWG to #4 AWG
  • Voltage Rating Description: 125/250 V
  • Width: 3.38 in

Certifications

  • EU RoHS Indicator: Contact Manufacturer

Overview

UPC 78358501544
Item Long Description Straight Blade Devices, Male Plug, Nylon, 4-Position, Heavy Duty, Industrial/CommercialGrade, Angled, 3-Pole 4-Wire Grounding, 30A 125/250V, 14-30P , Black, Single Pack.
GTiN 00783585015446
Length 4.5 in
Width 3.38 in
Size 4.5 in x 3.38 in x 2.37 in
Color Black
Voltage 250 Volt
Type Plug
Material Nylon
Cord Type All Portable
Applications Industrial/Commercial
Height 2.37 in
Weight 0.8 lb
Wire Size 12-4 AWG
Wattage 7500 Watt
Family Brand Name Hubbell Wiring Device Kellems
TC Connection Terminal Screws
Current 30 A
Number of Poles 3 Pole
Number of Wires 4
Sub Brand Straight Blade Devices
Standard CSA,File E1706,UL
Environmental Conditions Indoor Dry unless protected by additional means
