HCI MCMS14IDCL MCQK, FEM STR PLG, M
$57.20/ea
Usually ships within 6 to 8 Days
ea
Adding...
Already a Customer? Log in to view your pricing
Manufacturer Hubbell / Kellems
Mfg Catalog # MCMS14IDCL
North Coast Part # 753332

Features

  • Strain relief bushing protects terminations
  • Wire Guide for virtually toolless termination
  • Insulation displacement contacts are made of Copper Alloy

Specifications

General

  • Application: Quick Connect/Disconnect Signal and Control
  • Color: Black
  • EU RoHS Indicator: Yes
  • Item Type: Female Straight Plug
  • OEM Brand Name: Hubbell Wiring Device-Kellems
  • Performance: Electrical - Amperage - 6A | Electrical - Cable Diameters - .22" to .32" | Electrical - Voltage Rating - 50V AC/DC | Electrical - Wire Range - #18 AWG max., #22 AWG min. | Environmental - Ingress Protection - IP66 Suitability | Environmental - Operating Temperature - -20°C to 110°C
  • Temperature Rating: -20 Deg C to 105 Deg C
  • UPC: 783585226774

Dimensions

  • Diameter Live Part: .59"

Conductor Related

  • Conductor Type: Copper
  • Number Of Conductors: 4-Pole

Certifications and Compliance

  • Industry Standard(s): CSA Certified, C22.2 No. 182.3 and CSA C22.2 No. 94.2-07 | UL 2238 and UL50E, File No. E192071

Logistics

  • Carton Quantity: 25

Overview

UPC 78358522677
GTiN 00783585226774
Length 7.100 in
Width 1.100 in
Color Black
Type Female Straight Plug
Diameter .59"
Number of Conductors 4-Pole
Applications Quick Connect/Disconnect Signal and Control
Height 5.500 in
Temperature Rating -20 to 105 C
Family Brand Name Hubbell Wiring Device Kellems
Conductor Material Copper
Carton Qty 25
Sub Brand Micro-Quick Signal and Control Devices
Standard C22.2 No. 182.3,CSA,CSA C22.2 No. 94.2-07,File No. E192071,UL 2238,UL50E
