Hubbell Wiring Devices RCD101W 15 Amp 120 to 277 VAC 1-Pole White Quiet Rocker Switch
Product image thumbnail 0
Product image thumbnail 1
Product image thumbnail 2
Product image thumbnail 3
Product image thumbnail 4
$8.64/ea
ea
Adding...
Already a Customer? Log in to view your pricing
Manufacturer Hubbell / Kellems
Mfg Catalog # RCD101W
North Coast Part # 338595

Features

  • Smooth, quiet rocker
  • Low profile, less than 1 inch deep
  • Self-grounding feature is standard

Specifications

General

  • Action: Snap Switch
  • Actuator: Rocker
  • Application: Residential
  • Contact Configuration: Two Position
  • Environmental Conditions: Indoor Dry Unless Protected By Additional Means
  • Item Type: Decorator Switch Combo Devices
  • Material - Mounting Hardware: Mounting Screws
  • Number Of Poles: 2) Single Pole
  • OEM Brand Name: Hubbell Wiring Device-Kellems
  • Operating Cycles: 30,000 Minimum
  • Operating Temperature: Max Continuous- 60 Degrees C, Minimum- -20 Without Impact
  • Performance: Electrical - Dielectric voltage - Withstands 1,500V AC minimum for 1 minute | Electrical - Endurance - 30,000 cycles minimum | Electrical - Max. working voltage - 120V | Electrical - Overload - 1.5 times rating | Environmental - Flammability - UL V0 | Environmental - Operating temperatures - Maximum continuous 60°C | minimum -20°C (without impact) | Mechanical - Terminal accommodation - Back and side wire: #14 AWG min. - #12 AWG max. solid and stranded copper wire only | push wire: #14 AWG solid copper wire only
  • UPC: 883778110214

Dimensions

  • Display Size: Standard Size

Electrical Ratings

  • Amperage Rating: 15 A
  • Connectivity: Side Wired
  • Contact Rating: 15A
  • Current / Amperage Rating: 15 A
  • Current Rating: 15 A
  • Voltage Rating: 120/277V AC kV
  • Voltage Rating Description: 120/277V AC kV
  • Wattage: 4155

Certifications and Compliance

  • Industry Standard(s): CSA Certified | UL Listed E3896

Logistics

  • Carton Quantity: 10

Overview

UPC 88377811021
GTiN 00883778110214
Length 4.500 in
Finish Matte
Width 1.300 in
Size Standard Size
Color White
Operating Temperature Max Continuous- 60 Degrees C, Minimum- -20 Without Impact
Voltage 277 Volt
Type 2-Button, Standard Size
Applications Residential use
Mounting Type Flush, Screw
Height 1.200 in
Wattage 4,155 Watt
Temperature Rating 60 C Maximum Continuous, -20 C Minimum Continuous without Impact
Family Brand Name Hubbell
Carton Qty 10
TC Connection Side Wired
Actuator Rocker
Contact Configuration Two Position
Current 15 A
Contact Rating 15 A
Number of Poles 1 Pole
Operating Cycles 30000
Sub Brand Trade-Select
Standard CSA,E3896,UL
