KLRK NVSLCFG25BXG BLU LED FL 120-24
$1,170.66/ea
Usually ships within 11 to 17 Days
ea
Adding...
Already a Customer? Log in to view your pricing
Manufacturer Hubbell / Killark
Mfg Catalog # NVSLCFG25BXG
North Coast Part # 1166307

Features

NVSL Series flashing LED with very compact profile and 50,000 hours expected life. LED utilizes inverted cone design to provide full 360 degree coverage for more light projection. Flash rate for LED is 7 micro flashes approximately every second for increa

  • NVSL Series LED with very compact profile and 50,000 hours expected life steady - on or flashing.
  • NVSZ Series Xenon with 10,000 hours expected life flashing only.
  • LED utilizes inverted cone design to provide full 360 degree coverage for more light projection.
  • LED and Xenon available in five colors colors - red, green, amber, blue and clear.
  • Flash rate for LED is 7 micro flashes approximately every second for increased visual perception.
  • Xenon flash rate 60 to 80 per minute
  • Can be mounted in any orientation including lens in the UP or SIDE positions.
  • Materials: High strength 30% glass-filled thermoset polyester body with Lexan® lens. Resists corrosive effects of most chemicals, hydrocarbons and solvents
  • Designed for indoor and outdoor applications

Specifications

  • Color: Gray
  • Finish Type: Powder Epoxy Paint
  • Lamp Type: Steady
  • Light Source: LED
  • Material: Polyester, Fiberglass Reinforced
  • Mounting Type: Ceiling
  • Optic Type: Polycarbonate Globe - Blue
  • Series: NV
  • Type: Non-Metallic Corrosion Resistant Flashing Led Signal
  • UPC: 783936070544
  • Diameter - Inside: 1.14 in
  • Dimensions: 5.5 in x 17.5 in x 5.5 in
  • Gross Weight with Packaging: 2.1
  • Height: 5.5 in
  • Hub Size: 3/4"
  • Length: 5.5 in
  • Width: 17.5 in
  • Contact Rating: 60A INRUSH @ 120 VAC; 30A INRUSH @ 240 VAC; 15A INRUSH @ 480 VAC; 12A INRUSH @ 600 VAC; 6A BREAKING @ 120 VAC; 3A BREAKING @ 240 VAC; 1.5A BREAKING @ 480 VAC; 1.2A BREAKING @ 600 VAC; 10A CARRYING @ 120 VAC; 10A CARRYING @ 240 VAC; 10A CARRYING @ 480 VAC;
  • Frequency Rating: 50/60 Hz
  • Voltage Rating: 120-240 VAC

Hazardous Rating(s)

  • Class I, Division 2, Groups A, B, C, D
  • Class I, Zone 2, Groups IIC, IIB, IIA
  • Class II, Division 2, Groups F, G
  • Class III, Divisions 1 & 2
  • IP Rating: IP66

Overview

UPC 78393607054
GTiN 00783936070544
Length 5.5 in
Finish Powder Epoxy Paint
Width 17.5 in
Color Gray
Operating Temperature -40C to +40C
Voltage 120-240 Volt
Type Non-metallic corrosion resistant flashing LED signal
Material Fiberglass Reinforced,Polyester
Applications These new signal luminaires can be excellent warning devices in corrosive, wet NEMA 4X harsh environments, and in hazardous locations. NVS signals contain no exposed glass and carry Class II, F&G ratings required for many food processing areas.
Mounting Type Ceiling
Height 5.5 in
Frequency 50/60 Hz
Operating Voltage 120-240VAC
Family Brand Name Killark
Inside Diameter 1.14 in
Blade Dimensions 6.34" H x 4.54" W x 4.54" D
IP Rating IP66
Hub Size 3/4 in
Operating Frequency 50/60 Hz.
Sub Brand ENVIRORITE
