KLRK XCS-0MMG3 GREEN PUSH-PULL MAIN
$887.21/ea
Usually ships within 11 to 17 Days
ea
Adding...
Already a Customer? Log in to view your pricing
Manufacturer Hubbell / Killark
Mfg Catalog # XCS-0MMG3
North Coast Part # 683144
XCS SERIES - ALUMINUM MAINTAINED CONTACT PUSH/PULL BUTTON COVER WITHDEVICE - GREEN MUSHROOM BUTTON SUPPLIED WITH THREE NAMEPLATES("START/STOP", BLANK, "EMERGENCY STOP") - 1NO/1NC CONTACT RATING

Categories

Overview

UPC 78393689038
GTiN 00783936890388
Size 4-5/8" H x 3" W x 1-1/16" D
Voltage 600 Volt
Type Aluminum cover with push-pull button
Applications Hazardous locations due to the presence of flammable gases or vapors, combustible dusts, or easily ignitable fiber or flyings. Installations at petroleum refineries, chemical and petrochemical plants, and other processing or storage facilities where simil
Family Brand Name Killark
Certifications CSA,UL
Actuator Maintained Push Button
Contact Configuration 1-NO,1-NC
Amperage 0.55 Amp
Contact Rating 60A INRUSH @ 120 VAC; 30A INRUSH @ 240 VAC; 15A INRUSH @ 480 VAC; 12A INRUSH @ 600 VAC; 6A BREAKING @ 120 VAC; 3A BREAKING @ 240 VAC; 1.5A BREAKING @ 480 VAC; 1.2A BREAKING @ 600 VAC; 10A CARRYING @ 120 VAC; 10A CARRYING @ 240 VAC; 10A CARRYING @ 480 VAC;
Number of Poles 1 Pole
Action SP
