KLRK XCS-4K2A1 CLI XCS-0K2A1 CV W/1
$509.95/ea
Usually ships within 11 to 17 Days
ea
Adding...
Already a Customer? Log in to view your pricing
Manufacturer Hubbell / Killark
Mfg Catalog # XCS-4K2A1
North Coast Part # 1499668

Features

  • Copper free cast aluminum alloy.
  • Ground flange joint between bolted cover and box provide required flame path.
  • Push button, selector switches and pilot light operator bodies are copper-free aluminum.
  • Operating shaft in both push buttons and selector switches are stainless steel.

Specifications

  • Action: Maintained
  • Actuator: 2 Position Key Selector Switch
  • Ambient Temp. Range: UL: -25 to 40 ºC, CSA: -50 to 40 ºC, IEC: -20 to 40 °C
  • Application: Hazardous locations due to the presence of flammable gases or vapors, combustible dusts, or easily ignitable fiber or flyings. Installations at petroleum refineries, chemical and petrochemical plants, and other processing or storage facilities where simil
  • Back Box Type: SWB
  • Color: Black
  • Number Of Poles: 1
  • Series: XCS
  • Type: Aluminum Box And Cover With 2-Position Key Selector Switch
  • UPC: 783936891682
  • Depth: 5-1/32
  • Gross Weight with Packaging: 2.9
  • Hub Size: 1/2"
  • Amperage Rating: 10 A
  • Contact Rating: 60A INRUSH @ 120 VAC; 30A INRUSH @ 240 VAC; 15A INRUSH @ 480 VAC; 12A INRUSH @ 600 VAC; 6A BREAKING @ 120 VAC; 3A BREAKING @ 240 VAC; 1.5A BREAKING @ 480 VAC; 1.2A BREAKING @ 600 VAC; 10A CARRYING @ 120 VAC; 10A CARRYING @ 240 VAC; 10A CARRYING @ 480 VAC;
  • Frequency Rating: 50/60 Hz
  • CSA File Number: LR11714

Hazardous Rating(s)

  • Class I, Divisions 1 & 2, Groups C, D
  • Class I, Zones 1 & 2, Groups IIB, IIA
  • Class II, Divisions 1 & 2, Groups E, F, G
  • Class III, Divisions 1 & 2
  • UL File Number: E53360

Overview

UPC 78393689168
GTiN 00783936891682
Size 5-7/8" H x 3" W x 3-5/16" D
Color Black
Type Aluminum box and cover with 2-position key selector switch
Applications Hazardous locations due to the presence of flammable gases or vapors, combustible dusts, or easily ignitable fiber or flyings. Installations at petroleum refineries, chemical and petrochemical plants, and other processing or storage facilities where simil
Frequency 50/60 Hz
Family Brand Name Killark
Actuator 2-position selector switch
Contact Configuration 1-NO/1-NC
Amperage 10 Amp
Hub Size 1/2 in
Contact Rating 60A INRUSH @ 120 VAC; 30A INRUSH @ 240 VAC; 15A INRUSH @ 480 VAC; 12A INRUSH @ 600 VAC; 6A BREAKING @ 120 VAC; 3A BREAKING @ 240 VAC; 1.5A BREAKING @ 480 VAC; 1.2A BREAKING @ 600 VAC; 10A CARRYING @ 120 VAC; 10A CARRYING @ 240 VAC; 10A CARRYING @ 480 VAC;
Number of Poles 1 Pole
Enclosure Aluminum enclosure
Action SP
