KLRK XSX-23 SWITCH 1GANG 3P DEAD 3/
$688.03/ea
Usually ships within 11 to 17 Days
ea
Adding...
Already a Customer? Log in to view your pricing
Manufacturer Hubbell / Killark
Mfg Catalog # XSX-23
North Coast Part # 752784

Features

Enclosures are cast copper-free aluminum alloy. Operating shaft is stainless steel. Ground flange joint between bolted cover and box provide required flame path. Provisions for padlocking switch in either "ON" or "OFF" position is standard.

  • XSX Series (without overload protection) are ideally suited for across the-line applications where a positive disconnect means is required.
  • Enclosures are cast copper-free aluminum alloy.
  • Operating shaft is stainless steel.
  • Multiple gang assemblies available in combination with pilot lights, pushbuttons and switches on request.
  • Ground flange joint between bolted cover and box provide required flame path.
  • Provisions for padlocking switch in either “ON” or ”OFF” position is standard.

Specifications

  • Application: Provides manual starting and stopping of small AC or DC motors. Motor running protection when overload heaters are used. XSX Series (without overload protection) is ideally suited for across-the-line applications where a positive disconnect means is requi
  • Horsepower - Maximum: 10
  • Material: Copper-free aluminum
  • Series: XSX
  • Type: Aluminum Manual Motor Starting Switch Without Overload Protection
  • UPC: 783936933450
  • Gross Weight with Packaging: 2.57
  • Height: 5.75 in
  • Length: 7.625 in
  • Width: 4 in
  • Frequency Rating: 60 Hz
  • Power Factor: 0.9
  • Voltage Rating: 600 V
  • CSA File Number: LR11714

Hazardous Rating(s)

  • Class I, Divisions 1 & 2, Groups C, D
  • Class I, Zones 1 & 2, Groups IIB, IIA
  • Class II, Divisions 1 & 2, Groups E, F, G
  • Class III, Divisions 1 & 2

Overview

UPC 78393693345
GTiN 00783936933450
Length 7.625 in
Width 4 in
Size 5-15/16" H x 3" W x 4" D
Voltage 600 Volt
Type Aluminum manual motor starting switch without overload protection
Material Copper-Free Aluminum
Applications Provides manual starting and stopping of small AC or DC motors. Motor running protection when overload heaters are used. XSX Series (without overload protection) is ideally suited for across-the-line applications where a positive disconnect means is requi
Height 5.75 in
Frequency 60 Hz
Coil Voltage 2 HP @ 115 VAC; 7-1/2 HP @ 200-230 VAC; 10 HP @ 460-575 VAC.
Family Brand Name Killark
Number of Phases 3 Ph
Enclosure Type Aluminum enclosure
Power Rating 2 HP @ 115 VAC; 7-1/2 HP @ 200-230 VAC; 10 HP @ 460-575 VAC.
Number of Poles 3 Pole
Reset Type Lever
