HPW HBLALU24GBA618 PLUGTRAK, 20A, 2
Product image thumbnail 0
Product image thumbnail 1
Product image thumbnail 2
$198.19/ea
Usually ships within 11 to 17 Days
ea
Adding...
Already a Customer? Log in to view your pricing
Manufacturer Hubbell / Metal Raceway
Mfg Catalog # HBLALU24GBA618
North Coast Part # 1607185

Features

  • Multiple spacing configurations
  • Satin anodized scratch resistant finish
  • Hubbell designed and manufactured single receptacle
  • Insulation displacement wiring provides superior wire retention

Performance

  • Electrical - Receptacle Rating - NEMA 5-15R and NEMA 5-20R
  • Mechanical - Wire - #12 AWG Stranded Copper

Industry Standard(s)

  • CSA Standard C22.2 no. 62
  • E253976 /E253830 /E253833
  • UL Standard UL 5

Specifications

  • Buy Online - Web: No
  • Carton Quantity: 2
  • Current / Amperage Rating: 20 A
  • Item Type: Aluminum Pre-Wired PlugTrak
  • Length: 6 ft
  • Number Of Receptacles: 4
  • Type: Two Circuits
  • Voltage Rating: 125 VAC
  • Wire Size: #12 AWG THHN
  • EU RoHS Indicator: Contact Manufacturer
  • Each - Length: 74.000 in
  • Each - Height: 1.500 in
  • Each - Width: 2.500 in

Overview

UPC 78358511343
GTiN 00783585113432
Length 6 ft
Width 1.5 in
Voltage 125 Volt
Type Standard, Double Circuit, 1-Phase
Material Aluminum
Applications Permanently Installed
Height 1 in
Cable Size #12 AWG
Wattage 2500 Watt
Family Brand Name Hubbell Wiring Device Kellems
Carton Qty 2
Power Rating 2500 W
Number of Outlets 4
Current 20 A
Enclosure NEMA 1
Sub Brand PlugTrak
Environmental Conditions Indoor Only
