Usually ships within 11 to 17 Days
Already a Customer? Log in to view your pricing
Manufacturer Hubbell / Metal Raceway
Mfg Catalog # PB2B10
North Coast Part # 153460


  • UL Listed and CSA Certified to 600 volts
  • Single and two channel latching raceways are dual-rated for both power and data applications, reducing inventory requirements



  • Application: 10' Base
  • Color: Office White
  • Construction: Extruded Plastic
  • Cover Type: Removable
  • EU RoHS Indicator: No
  • Enclosure Type: NEMA 1 Rating
  • Item Type: PB2, 2-Channel BaseTrak
  • Knockouts: None
  • Material: Thermoplastic
  • OEM Brand Name: Hubbell Wiring Device-Kellems
  • Performance: Environmental - Flame Rating - UL94V-0 | Environmental - Temperature Range - -25.6° to 158° F
  • Series: PB2
  • Style: Two Channel
  • Type: Base Only
  • UPC: 783585310008


  • Length: 10 ft
  • Width: 4.5 in

Certifications and Compliance

  • Industry Standard(s): CSA Standard C22.2 no. 62 | E118895 / E119190 | UL Standard UL 5A
  • Non Hazardous Location: Non Hazardous


  • Carton Quantity: 60


UPC 78358531000
GTiN 00783585310008
Length 10 ft
Finish Office White
Width 4.5 in
Color Office White
Type Standard, Extruded, 2-Channel
Material Thermoplastic
Product Series PB2
Applications 10' Base
Height 1.42 in
Family Brand Name Hubbell Wiring Device Kellems
Construction Extruded Plastic
Carton Qty 60
Blade Dimensions 10 ft L x 4.5 in W x 1.42 in H
Cover Type Removable
Enclosure NEMA 1 Rating
Used With PB2 BaseTrak Series Raceway
Sub Brand BaseTrak
Standard CSA Standard C22.2 No. 62,E118895,E119190,UL Standard UL 5A
