RACO 686 7-5/8 x 5-31/32 x 2-1/2 Inch 47.8 In Pre-Galvanized Steel FM Bracket Mount Multi-Device Welded Switch Box
Product image thumbnail 0
Product image thumbnail 1
Product image thumbnail 2
$4,056.57/c (100 ea)
ea
Adding...
Already a Customer? Log in to view your pricing
Manufacturer Hubbell / Raco
Mfg Catalog # 686
North Coast Part # 264275

Features

  • Reference the Box Selection section in the front of this catalog for complete description of bracket types and features.
  • Supplied with eleven (11) 1/2 and 3/4 in. concentric knockouts
  • Welded steel construction with "FM" bracket - 1/2 in. set back
  • Standard device spacing with tapped 6-32 holes for devices
  • Uses Raco 971 voltage partition
  • 47.8 cu. in. capacity

Specifications

General

  • Bracket Setback: 0.50
  • Bracket Type: FM, for Metal or Wood Studs
  • Color: Gray
  • Drawn or Welded: Welded
  • Knockouts: 1/2 in;3/4 in
  • Material: Steel
  • Number of Gang(s): 3-Gang
  • UPC: 050169006863
  • Wiring System: Conduit

Dimensions

  • Cubic Capacity: 47.8 cu.in
  • Depth: 2.5 in
  • Height: 7.625 in
  • Weight: 1.379 lb
  • Width: 6.97 in

Certifications and Compliance

  • Certified Listed: UL Listed

Logistics

  • Carton Quantity: 10 EA
  • Packaging Type: No Packaging
  • Pallet Quantity: 600 EA

Type

  • Box
  • Large Capacity

Overview

UPC 05016900686
GTiN 00050169006863
Width 6.97 in
Size 2-1/2 IN
Color Gray
Type Multi-device switch box
Material Steel
Applications Electrical
Depth 2.5 in
Height 7.625 in
Weight 1.379 lb
Family Brand Name Raco
Construction Welded
Cable Entry Knockouts for conduit
