Hubbell Wiring Devices L630C 30 Amp 250 Volt 2-Pole 3-Wire NEMA L6-30R Black and White Locking Connector Body
Product image thumbnail 0
Product image thumbnail 1
Product image thumbnail 2
$29.70/ea
ea
Adding...
Already a Customer? Log in to view your pricing
Manufacturer Hubbell / Select Spec
Mfg Catalog # L630C
North Coast Part # 16241

Specifications

  • Max Working Voltage: 600V AC, 250V DC
  • Locking Device Listings and Approvals: UL Listed, CSA Certified
  • Locking Device Product: Connector Body
  • Terminal Identification: Terminals identified in accordance with UL 498 (Brass, White, Green).
  • Temperature Rise: Maximum 30 deg C. temperature rise at full rated current after 50 cycles overload at 150% rated current for either AC or DC applications per UL 498
  • Features: Nylon Construction, Visible NEMA Ratings, Captive Assembly Screws
  • Locking Device NEMA Configuration: L6-30R
  • Contacts/Blade Material: High Performance Copper Alloy
  • Current Interrupting: Certified for current interrupting at full rated current.
  • Locking Device Color: Black & White
  • Overload: Minimum 4.8 times rated current for 100 cycles.
  • Product Identification: Ratings and NEMA identification are permanently marked on device.
  • Operating Temperatures: Maximum Continuous 60 deg C, minimum -40 deg c. (w/o impact).
  • Terminal Accommodation: #18 to #8 AWG Flexible Cord
  • Dielectric Voltage: Withstands 3,500V per UL498
  • Locking Device Rating: 30A, 250V
  • Blade/Contact Holder: Impact Modified Nylon
  • Locking Device Wiring Scheme: 2 Pole, 3 Wire Grounding
  • Body: Supertough Nylon
  • Flammability: HB or Better per UL 94 or CSA 22.2 No. 17
  • SELECTSPEC Product Type: Locking Devices

Product Drawings / Installation Instructions

Product

Overview

UPC 78358583597
Item Long Description Locking Devices, SELECT SPEC Twist-LockĀ®, Commercial/Industrial, Female Connector Body, 30A 250V, 2-Pole 3-Wire Grounding, L6-30R, Screw Terminal, Black
GTiN 00783585835976
Size Standard
Color Black/White
Operating Temperature -40 C
Type Hubbell Pro
Number of Conductors 3-Wire Grounding
Applications Heavy Duty
Temperature Rating -40 to 75/-25 to 75 C
Family Brand Name Hubbell Wiring Device Kellems
TC Connection Screw Terminals
Number of Poles 2 Pole
Sub Brand Twist-Lock
Voltage 250 Volt
